Product Details:
|
| Brightness: | 200 Cd/m2 (Typ.) | Name: | TFT-LCD Panel |
|---|---|---|---|
| Active Area: | 309.399×173.952 Mm | Frequency: | 60Hz |
| Surface: | Glare | Display Colors: | 262K (6-bit) |
| High Light: | Glare Chimei Lcd Monitor,TFT Chimei Lcd Monitor,EE080NA-04C TFT LCD Panel |
||
Glare Chimei Lcd Monitor EE080NA-04C TFT LCD Panel Hard Coating
Description :
| Panel Brand : | CHIMEI INNOLUX |
| Panel Model : | EE080NA-04C |
| Panel Type : | a-Si TFT-LCD , CELL |
| Panel Size : | 8.0 inch |
| Resolution : | 1024(RGB)×768 , XGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 162.048×121.536 mm |
| Outline : | 170.9×132.4 mm |
| Surface : | Hard coating |
| Glass Depth : | 0.50+0.50 mm |
| Transmissivity : | 4.2% (Typ.)(with Polarizer) |
| Contrast Ratio : | 700:1 (Typ.) |
| Display Colors : | 262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 50% |
| Response Time : | 6/14 (Typ.)(Tr/Td) |
| Viewing Angle : | 75/75/75/75 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Signal Interface : | LVDS (1 ch, 6/8-bit) , 40 pins |
| Input Voltage : | 3.3/11.8/22/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
Laptop lcd and led screen:from 4.5 inch to 18.4 inch
1.Size:8.9",10.1",10.2",11.1",11.6",12.1",13.1,13.3",14.0",14.1" , 15.0",15.4",15.6",16.0",17.0",17.3",18.4"
2. Resolution:WSVGA,WXGA,WXGAHD,XGA,WXGA+,WXGA++
3. Backlight:LED,1CCFL,2CCFL
More Information For N&S electronic Co.,LTD:
1. Agent Brand:
* AUO/CPT/CMO/ /Innolux/ TianMa five brands tft lcd moulds in China from 2010, you can get the most competitive price for real products.
2. Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from N&S you can enjoy the real panels directly from original factory; Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them.
3. Quickly delivery:
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from HKSEBO you can get more convenient delivery;
Trade Terms:
1. Payment terms: 100% by T/T when order confirmed
2. Lead time: 2-5 working days according to the order quantity
3. Sample lead time: within 3 working days after we get payment.
4. The price based on FOB Shenzhen,we will offer best discount according to order quantity.
5. Warranty:offer free spare parts within ONE year.
6. Offer OEM service for batch orders,to print logo and design box.
Pictures of EE080NA-04C LCD Display:
