Product Details:
|
| Display Colors: | 262K (6-bit) | Brightness: | 350cd/m² (Typ.) |
|---|---|---|---|
| Lamp Type: | 4S1P WLED | Signal Interface: | CMOS (1 Ch, 6-bit) , 67 Pins |
| Resolution: | 320(RGB)×240 , QVGA | Display Mode: | ASV, Normally Black, Transmissive |
| High Light: | sharp lcd display panels,sharp lcd flat screen |
||
2.5 inch Sharp LCD Panel LQ025Q3DW02 ASV, Normally Black, Transmissive with 320*240
Our Services
1. Quick and accurate reply with best service attidue to our business
2. Pofessional advise
3. Quick PI confirmation
4. Close production follow up and production process feedback
5. Safe package
6. Get feekback from your side when items arrived,
7. 24 months warranty for items
Advantages of N&S For the TFT LCD Screen:
SHARP LQ025Q3DW02 General Features
Panel Brand : SHARP
Panel Model : LQ025Q3DW02
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 2.5 inch
Resolution : 320(RGB)×240 , QVGA
Display Mode : ASV, Normally Black, Transmissive
Active Area : 49.92×37.44 mm
Outline : 56.8×48.8×3.3 mm
Surface : Antiglare
Brightness : 350 cd/m² (Typ.)
Contrast Ratio : 500:1 (Typ.)
Display Colors : 262K (6-bit)
Response Time : 15/15 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 4S1P WLED
Signal Interface : CMOS (1 ch, 6-bit) , 67 pins
Input Voltage : 3.3/3.3V (Typ.)(VDDIO/VCI)
Mechanical Features
| Panel Size : | 2.5 inch |
| Dot Resolution : | 320(RGB)×240 (QVGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 162 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.052×0.156 mm (H×V) |
| Pixel Pitch : | 0.156×0.156 mm (H×V) |
| Weight : | 25g (Max.) |
| Surface : | Antiglare |
| Active Area : | 49.92×37.44 mm (H×V) |
| Bezel Area : | 51.4×38.9 mm (H×V) |
| Outline Dimension : | 56.8×48.8 mm (H×V) |
| Outline Depth : | 3.1±0.2 mm |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
SHARP LQ025Q3DW02 Optical Features
Display Mode : ASV, Normally Black, Transmissive
Brightness : 350 cd/m² (Typ.)
Contrast Ratio : 500 : 1 (Typ.) (Transmissive)
Display Color : 262K (6-bit)
Response Time : 15/15 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.310; Wy:0.340
more details.
| Step1 | Send us inquiry or leave us message online, indicating us following information |
| 1. LCD screen model NO., quantities, and colors you want to order | |
| 2. your name, email and address | |
| 3. the payment and shipment method which are convenient to you | |
| 4. anything else you would like to know | |
| Step 2 | We will get back to you with our best price and the shipping cost very quickly, and answer all your concerned questions in details |
| Step 3 | After order confirmed, you can choose to pay the money by T/T, Paypal, Western and then provide us your delivery address and phone number |
| Step 4 | Sit back and wait patiently. Goods will be shipped out within 3 days, we will send the tracking number to your email once shipped out. |
| Step 5 | After you receive the goods, please let us know if it is in good condition, and your suggestions are welcome. |
Questions & Answers:
Q1: How can you trust us?
- We are a professional team for the LCD panel international trade already for 6 years. We own the more professional & more competitive sourcing line & agency for the LCD Screen panels.
Q2: When can I get the update price?
- Within 24 hours after we get your inquiry.
Q3: What is your product capacity per day?
- 500-1000 pcs/day. We test each pcs LCD panels before shipment.
Q4: What is the payment term?
- T/T, Western Union, MoneyGram, PayPal.
Q6: Do you offer after-sale service?
- Yes, we do. We have strict QC system to make sure within our guarantee period(12 months), please contact us ASAP if there is any question, we will try our best to resolve it.
Q7: Which brands' LCD panel replacements could we handle?
- Our LCD screen panels contained but not limited to AUO, Chimei, Hitachi, Innolux, KOE, Tianma, LG, NEC, Samsung, Sharp, Optrex and more brand for the industrial TFT LCD module.
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| LM016LC1S07 | SHARP | 1.9" | 96×128 |
| LS050K3SX06A | SHARP | 5.0" | 720×1280 |
| LK460D3HA10 | SHARP | 46" | 1920×1080 |
| LK315T3HB874 | SHARP | 31.5" | 1366×768 |
| LK315T3HB873 | SHARP | 31.5" | 1366×768 |
| LQ0DZC0156 | SHARP | 40" | 1920×1080 |
