Hard Coating Surface Sharp LCD Panel LQ035Q7DB02 3.5 Inch 240×320 Industrial Application

Hard Coating Surface Sharp LCD Panel LQ035Q7DB02 3.5 Inch 240×320 Industrial Application

    • Hard Coating Surface Sharp LCD Panel LQ035Q7DB02 3.5 Inch 240×320 Industrial Application
    • Hard Coating Surface Sharp LCD Panel LQ035Q7DB02 3.5 Inch 240×320 Industrial Application
  • Hard Coating Surface Sharp LCD Panel LQ035Q7DB02 3.5 Inch 240×320 Industrial Application

    Product Details:

    Place of Origin: Japan
    Brand Name: SHARP
    Certification: ISO9001
    Model Number: LQ035Q7DB02

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
    Delivery Time: 1-3 Working Days
    Contact Now
    Detailed Product Description
    Panel Model: LQ035Q7DB02 Panel Brand: SHARP
    Descrition: 240×320 Panel Type: A-Si TFT-LCD
    Active Area: 53.64×71.52 Mm Outline: 65×85×4.8 Mm

    LQ035Q7DB02 SHARP a-Si TFT-LCD ,3.5 inch, 240×320 for Industrial Application

    LQ035Q7DB02 Basic Information



    Panel Model LQ035Q7DB02
    Panel Brand SHARP
    Descrition a-Si TFT-LCD ,3.5 inch, 240×320
    Panel Type a-Si TFT-LCD
    Operating Temperature -10 ~ 60 °C
    Storage Temperature -25 ~ 70 °C
    Remarks AD-TFT (Advanced TFT)





    Packaging & Delivery

    Packaging: Safety Package For all of our LCD Screen Panel Replacements.

    Details: 1. Antistatic bag

    2. Layers of cartons

    3. Foam Box

    4. Carton Box.

    LQ035Q7DB02 Mechanical Features

    Dot Resolution 240(RGB)×320 (QVGA)
    Pixel Configuration RGB Vertical Stripe
    Pixel Density 113 PPI
    Aspect Ratio 3:4 (H:V)
    Form Factor Flat Rectangle Display
    Dot Pitch 0.0745×0.2235 mm (H×V)
    Pixel Pitch 0.2235×0.2235 mm (H×V)
    Weight 50g (Typ.)
    Surface Hard coating (3H)
    Active Area 53.64×71.52 mm (H×V)
    Bezel Area 57.4×75.2 mm (H×V)
    Outline Dimension 65×85 mm (H×V)
    Outline Depth 4.5±0.3 mm
    Landscape or Portrait Portrait type
    Touch Panel Embeded (4-wire Resistive)



    Guarantee:

    (1) All items will be strictly tested and shipped with safe & professional package.

    (2) We have 12 months warranty for each LCD screen panel, depend on the different LCD panel models.

    (3) We will do our best to solve any possible problems for your after sale sevice. Please contact with us if any problems.

    LQ035Q7DB02 Optical Features

    Display Mode TN, Normally White, Transflective
    Brightness 50 cd/m² (Typ.)
    Contrast Ratio 8:1 (Typ.) (Reflective)
    Display Color 262K (6-bit)
    Response Time 30/50 (Typ.)(Tr/Td)
    Viewing Angle 40/40/40/50 (Typ.)(CR≥2) (L/R/U/D)
    Viewing Direction 6 o'clock
    White color Chromaticity Wx:0.320; Wy:0.340
    Reflectance Ratio 7/11% (Min./Typ.)
    Sunlight Readable Y



    The reasons you choose us

    1).Mor e competitive price! As a professional LCD Distributor, we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the h

    ard-to-find LCD panels.

    2).Great quality! All LCD Screen we sent are with good quality guarantee, 100% quality check and full one year warranty!
    3).Fast delievery! Delivery time will be faster than others.
    4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time, so we could promise save much more money on the shipping cost and better service is offered!
    5).Best sale-service! Professional team to service with you before sale, on sale & after service.

    LQ035Q7DB02 Electronics Feature

    Vertical Frequency 60Hz
    Reverse Scan Yes (U/D, L/R)







    Below are our other LCD panels stock for your easy reference:

    Panel Model Brand Size Resolution
    LM12S40 SHARP 12.1" 800×600
    LM80C24 SHARP 11.3" 800×600
    LM64C391 SHARP 11.3" 640×480
    LM11X30 SHARP 11.1" 1024×600
    LM10V33 SHARP 10.4" 640×480
    LM9V38 SHARP 9.4" 640×480
    LM32008F SHARP 4.7" 320×240
    LM320081 SHARP 4.7" 320×240

    We also have other industrial LCD panels, pls contact to us for the further information





    LQ035Q7DB02   pictures
