Product Details:
|
| Panel Type: | CSTN-LCD | Display Mode: | STN, Normally Black, Transmissive |
|---|---|---|---|
| Panel Size: | 8.1 Inch | Resolution: | 640×240 |
| Contrast Ratio: | 50:1 (Typ.) | Aspect Ratio: | 8:3 (H:V) |
| Brightness: | 80 Cd/m² (Typ.) | ||
| High Light: | sharp lcd display panels,sharp lcd flat screen |
||
Normally Black 8.1 inch LM8M64 SHARP LCD Display Module Active Area 191.98×71.98 mm 640×240 resolution
Why do you choose us?
• Quick response to clients' enquiries within 24hrs.
• More than 6-yearexperience in LCD screen field and professional team communication team.
•Value quality and long-term cooperation to reach win-win relationship.
Packing & Delivery for our LCD Screen Panel Replacements:
1. Anti-static Bag Packing.
2. Anti-Shock Bubble Bag Packing
3. Foam and Hard Carton Packing
4. Picked up by forward and delivered by express services.
LM8M64 Basic Information
| Panel Model | LM8M64 |
| Panel Brand | SHARP |
| Descrition | CSTN-LCD ,8.1 inch, 640×240 |
| Panel Type | CSTN-LCD |
| Operating Temperature | 0 ~ 40 °C |
| Storage Temperature | -25 ~ 60 °C |
| Remarks | for NEC MobilePro 750, 770 |
LM8M64 Mechanical Features
| Dot Resolution | 640(RGB)×240 (HVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 84 PPI |
| Aspect Ratio | 8:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.100×0.300 mm (H×V) |
| Pixel Pitch | 0.300×0.300 mm (H×V) |
| Weight | 175g |
| Active Area | 191.98×71.98 mm (H×V) |
| Bezel Area | 196.6×76.3 mm (H×V) |
| Outline Dimension | 225.4×87.4 mm (H×V) |
| Outline Depth | 7.0 (Max.) mm |
| Holes & Brackets | Face mounting holes |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
LM8M64 Optical Features
| Display Mode | STN, Normally Black, Transmissive |
| Brightness | 80 cd/m² (Typ.) |
| Contrast Ratio | 50 : 1 (Typ.) (Transmissive) |
| Display Color | Color () |
| Response Time | 270/80 (Typ.)(Tr/Td) |
| White color Chromaticity | Wx:0.320; Wy:0.329 |
| Sunlight Readable | N |
