Product Details:
|
| Panel Type: | FSTN-LCD | Active Area: | 127.16×67.8 Mm |
|---|---|---|---|
| Resolution: | 240×128 | Panel Size: | 5.7 Inch |
| Response Time: | 400 (Typ.)(Tr+Td) | Lamp Type: | 1 Pcs CCFL |
| High Light: | sharp lcd display panels,sharp lcd flat screen |
||
LM24P20 FSTN-LCD Module 5.7 inch with 127.16×67.8 mm Active Area,240×128 Resolution new and original
LM24P20 Basic Information
| Panel Model | LM24P20 |
| Panel Brand | SHARP |
| Descrition | FSTN-LCD ,5.7 inch, 240×128 |
| Panel Type | FSTN-LCD |
| Operating Temperature | 0 ~ 45 °C |
| Storage Temperature | -25 ~ 60 °C |
| Remarks | Color:Black/White |
LM24P20 Optical Features
| Display Mode | STN, Black/White mode, Transmissive |
| Brightness | 50 cd/m² (Typ.) |
| Contrast Ratio | 20 : 1 (Typ.) (Transmissive) |
| Display Color | Monochrome () |
| Response Time | 400 (Typ.)(Tr+Td) |
| Sunlight Readable | N |
LM24P20 Mechanical Features
| Dot Resolution | 240×128 |
| Pixel Configuration | Rectangle |
| Pixel Density | 47 PPI |
| Aspect Ratio | 17:9 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.53×0.53 mm (H×V) |
| Pixel Pitch | 0.53×0.53 mm (H×V) |
| Weight | 430g |
| Active Area | 127.16×67.8 mm (H×V) |
| Outline Dimension | 194×96 mm (H×V) |
| Outline Depth | 19.0 (Max.) mm |
| Holes & Brackets | Face mounting holes |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.
2. Great quality and high purity
Good quality is one secret for our success.
3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
24/7 is available. Try our best to solve various problems customers encountered!
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LK315T3HC1K | SHARP | 31.5" | 1366×768 |
| LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
| LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
| LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
| LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
| LQ156D1JX02 | SHARP | 15.6" | 3840×2160 |
| LQ156Z1JW01 | SHARP | 15.6" | 3200×1800 |
| LQ133T1JW14B | SHARP | 13.3" | 2560×1440 |
| LQ047K3SX04 | SHARP | 4.7" | 720×1280 |
| LS024Q8UC92 | SHARP | 2.4" | 240×320 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Quality Control:
Make sure No damage, No Scratches, No dusty, No light leakage.
Make sure all functions are 100% tested ok
