Product Details:
|
| Panel Model: | LQ201U1LW32 | Panel Type: | A-Si TFT-LCD |
|---|---|---|---|
| Panel Size: | 20.1 Inch | Resolution: | 1600×1200 |
| Outline: | 436×335×20.4 Mm | Surface: | Antiglare, Hard Coating (2H) |
| High Light: | sharp lcd screen,sharp lcd flat screen |
||
Normally Black LQ201U1LW32 20.1 inch resolution1600×1200 Surface Antiglare, Hard coating (2H)
LQ201U1LW32 Basic Information
| Panel Model | LQ201U1LW32 |
| Panel Brand | SHARP |
| Descrition | a-Si TFT-LCD ,20.1 inch, 1600×1200 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -25 ~ 60 °C |
LQ201U1LW32 Mechanical Features
| Dot Resolution | 1600(RGB)×1200 (UXGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 99 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.085×0.255 mm (H×V) |
| Pixel Pitch | 0.255×0.255 mm (H×V) |
| Weight | 2.40Kgs (Max.) |
| Surface | Antiglare, Hard coating (2H) |
| Active Area | 408×306 mm (H×V) |
| Bezel Area | 413.2×311.2 mm (H×V) |
| Outline Dimension | 436×335 mm (H×V) |
| Outline Depth | 20.4 (Max.) mm |
| Holes & Brackets | Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Packaging & Delivery
Packaging Details:
Antistatic bag + Bubble bag + Foam box + Carton box
Delivery Detail:
1-3 working days after payment confirmed
FAQ
1. Q: Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
2. Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3. Q: What about the lead time for mass production?
A: It depends on your order quantity and the season you place the order.
4. Q: What are your terms of payment?
A: We accept T/T, Western Union, MoneyGram, PayPal.
