Product Details:
|
| Panel Type: | A-Si TFT-LCD | Active Area: | 36.72×48.96 Mm |
|---|---|---|---|
| Outline: | 42.72×60.26×2.45 Mm | Contrast Ratio: | 500:1 (Typ.) |
| Size: | 2.4 Inch | Frequency: | 60Hz |
| High Light: | black and white lcd display,lcd panel screen |
||
Products Information:
|
Panel Model |
TM024HDH49 |
|---|---|
|
Panel Brand |
TIANMA |
|
Descrition |
a-Si TFT-LCD ,2.4 inch, 240×320 |
|
Panel Type |
a-Si TFT-LCD |
|
Display Mode |
TN, Normally White, Transmissive |
|
Active Area |
36.72×48.96 mm |
|
Outline |
42.72×60.26×2.45 mm |
|
Surface |
Clear, Hard coating (3H) |
|
Contrast Ratio |
500:1 (Typ.) |
|
Display Colors |
262K , CIE1931 53% |
|
Response Time |
20 (Typ.)(Tr+Td) |
|
Viewing Angle |
70/70/70/60 (Typ.)(CR≥10) (L/R/U/D) |
|
Frequency |
60Hz |
|
Lamp Type |
1S3P WLED Without Driver |
|
Signal Interface |
8/9/16/18-bit 8080 parallel , 44 pins |
|
Input Voltage |
(1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
Packaging & Delivery
· Delivery Lead Time :2~3 weeks
· Minimum Order :1 pcs LCD Panel
· Supply Ability :100 PCS / Per Day
TM024HDH49 Mechanical Features
|
Dot Resolution |
240(RGB)×320 (QVGA) |
|---|---|
|
Pixel Configuration |
RGB Vertical Stripe |
|
Pixel Density |
166 PPI |
|
Aspect Ratio |
3:4 (H:V) |
|
Form Factor |
Flat Rectangle Display |
|
Dot Pitch |
0.051×0.153 mm (H×V) |
|
Pixel Pitch |
0.153×0.153 mm (H×V) |
|
Weight |
TBD |
|
Surface |
Clear, Hard coating (3H) |
|
Active Area |
36.72×48.96 mm (H×V) |
|
Outline Dimension |
42.72×60.26 mm (H×V) |
|
Outline Depth |
2.25±0.2 mm |
|
Landscape or Portrait |
Portrait type |
|
Touch Panel |
Without |
