Product Details:
|
| Model:: | TM070DDH08 | MFG:: | Tianma LCD Displays |
|---|---|---|---|
| Resolution :: | 1024×600 | Brightness :: | 250 |
| C/R:: | 500:1 | Backlight :: | WLED |
| High Light: | lcd display white screen,lcd panel screen |
||
TIANMA 6.0 inch HD TFT LCD Screen with Touch Panel TM060RBH01 WVGA 800(RGB)*480 S6000TV Screen
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 2~10 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange professional sales team to follow up your case.
7.0 inch HD TFT LCD Digital Screen
Panel Brand: TIANMA
Panel Model: TM070DDH08
Panel Type: a-Si TFT-LCD, Panel
Panel Size: 7.0 inch
Resolution: 1024(RGB)*600, WSVGA
Display Mode: TN, Normally White, Transmissive
Surface: Antiglare
Brightness: 250 cd/m2 (Typ.)
Contrast Ratio: 500:1 (Typ.)
Display Color: 262K / 16.7M (6-bit / 6-bit + Hi-FRC)
Response Rime: 20 (Typ.) (Tr+Td) (ms)
Viewing Angle: 75/75/70/75 (Typ.) (CR≥10) (L/R/U/D)
Frequency: 60Hz
Lamp Type: 3S6P WLED
Signal Interface: Parallel RGB (1 ch, 6/8-bit)
Input Voltage: 3.3/11/20/-6.8V (Typ.) (VCC/AVDD/VGH/VGL)
RoHS
Application: All MP4 PMP Panel
| Panel Brand : | Tianma |
|---|---|
| Panel Model : | TM070DDH08 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Application : | Machine |
| Operating Temperature : | -20 ~ 70 °C |
| Storage Temperature : | -30 ~ 80 °C |
| RoHS : | ROHS |
| Specific Feature : |
NA |
