Product Details:
|
| Name: | Auo Touch Panel | Model: | G190ETN01.4 |
|---|---|---|---|
| Diagonal Size: | 19.0 Inch | Type: | A-Si TFT-LCD |
| Frame Rate: | 60Hz | Touch Panel: | Without |
| High Light: | G190ETN01.4 AUO Touch Panel,19 Inch AUO Touch Panel,Anti Glare AUO LCD Screen |
||
G190ETN01.4 AUO 19 inch LCM 1280×1024 Touch screen
| Panel Model | G190ETN01.4 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,19.0 inch, 1280×1024 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 376.32×301.06 mm |
| Outline | 396×324×13.38 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC) , CIE1931 90% |
| Response Time | 7/3 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 4 strings WLED Embedded (LED Driver) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins |
| Input Voltage | 5.0V (Typ.) |
| Panel Model | G190ETN01.4 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,19.0 inch, 1280×1024 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -30 ~ 85 °C |
| Storage Temperature | -30 ~ 85 °C |
| Dot Resolution | 1280(RGB)×1024 (SXGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 86 PPI |
| Aspect Ratio | 5:4 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.098×0.294 mm (H×V) |
| Pixel Pitch | 0.294×0.294 mm (H×V) |
| Weight | 1.80Kgs (Typ.) |
| Surface | Antiglare, Hard coating (3H) |
| Active Area | 376.32×301.06 mm (H×V) |
| Bezel Area | 379.72×304.46 mm (H×V) |
| Outline Dimension | 396×324 mm (H×V) |
| Outline Depth | 13.38 (Max.) mm |
| Holes & Brackets | Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Feature Of AUO LCD Panel
Advantage Of AUO LCD Panel
We also have other industrial LCD panels, pls contact to us for the further information
