Product Details:
|
| Size: | 12.1 Inch | Composition: | LCM |
|---|---|---|---|
| Resolution: | 1280×800 | Brightness: | 450 |
| C/R: | 1000:1 | View Angle: | 85/85/85/85 |
| Colors: | 16.7M | Backlight: | WLED |
| Best View On: | Symmetry | Touch Screen: | Without |
| High Light: | lcd display white screen,lcd panel screen |
||
1. TIANMA TM121JDSG10 Mechanical Details
| Pixel Features : | Pixel Format | 1280(RGB)×800 [WXGA] | Dot Pitch | 0.068×0.204 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.204×0.204 mm (H×V) | |
| Mechanical Size : | Display Area | 261.12×163.2 mm (H×V) | Bezel Area | 262.12×164.2 mm (H×V) |
| Outline Dim. | 278×184 mm (H×V) | Outline Depth | 9.9/10.4 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:10 (H:V) | Shape Style | - | |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Weight |
440g (Typ.)
|
Surface | Antiglare |
2. TIANMA TM121JDSG10 Optical Details
| Basic Information : | Brightness | 450 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Optical Mode | SFT, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 12/13 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.316; Wy:0.350 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6200K | White Uniformity | 1.33/1.43 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 39% | sRGB | 55% coverage |
| Adobe RGB | 41% coverage | DCI-P3 | 41% coverage | |
| Rec.2020 | 29% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
3. TIANMA TM121JDSG10 Backlight Details
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 50K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | With LED Driver |
| Driver Electrical : | Voltage Input | 10/12/15V (Min./Typ./Max.) | Current Input | 660mA (Typ.) | ||
| Consumption | 7.20W (Typ.) | |||||
4. TIANMA TM121JDSG10 Interface Details
| Signal Systerm : | LVDS (1 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 660mA (Typ.) | ||
| Consumption | 2.18W (Typ.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Mode | Pin Pitch | Pins | Amount | Configuration |
| STARCONN | 093G30-B0001A-G4 | 1.0 mm | 30 pins | 1 pcs | ||
