Product Details:
|
| Panel Model: | NL6448BC20-14 | Panel Type: | A-Si TFT-LCD , LCM |
|---|---|---|---|
| Panel Size: | 6.5 Inch | Surface: | Clear, Hard Coating (2H), Antireflection |
| Brightness: | 500 Cd/m² (Typ.) | Contrast Ratio: | 400:1 (Typ.)(Transmissive) |
| High Light: | nec lcd touch screen,nec lcd screen |
||
6.5 inch NL6448BC20-14 NEC LCD Panel with 132.48×99.36 mm for Industrial Application
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
NL6448BC20-14 Detailed Product Description
| Panel Brand : | NEC |
| Panel Model : | NL6448BC20-14 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 6.5 inch |
| Resolution : | 640(RGB)×480 , VGA |
| Display Mode : | TN, Normally White, Transflective |
| Active Area : | 132.48×99.36 mm |
| Outline : | 178.8×126.8 mm |
| Surface : | Clear, Hard coating (2H), Antireflection |
| Brightness : | 500 cd/m2 (Typ.) |
| Contrast Ratio : | 400:1 (Typ.)(Transmissive) |
| Display Colors : | 262K (6-bit) , CIE1931 42% |
| Response Time : | 13/36 (Typ.)(Tr/Td) |
| Viewing Angle : | 50/50/35/45 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 2 pcs CCFL |
| Signal Interface : | CMOS (1 ch, 6-bit) , 31 pins |
| Input Voltage : | 3.3/5.0V (Typ.)(VCC) |
Our Service
1. Small quantity also can be provided.
2. New models can be updated fast.
3. We have strict QC team to make sure all products are qualified before delivery.
4. Warranty promise
5. Sourcing line for different hard disks for different brands
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| NL10276BC24-21BD | NLT | 12.1" | 1024×768 |
| NL10276BC20-18KH | NLT | 10.4" | 1024×768 |
| NL8048BC19-02BD | NLT | 7.0" | 800×480 |
| NL160120BM27-07 | NLT | 21.3" | 1600×1200 |
| NL2432HC22-36B | NLT | 3.5" | 240×320 |
| NL256204AM15-02A | NLT | 20.1" | 2560×2048 |
| NL12876BC26-25A | NLT | 15.3" | 1280×768 |
| NL8060BC26-28N | NLT | 10.4" | 800×600 |
| NL4864HL11-01A | NLT | 3.5" | 480×640 |
| NL204153AM21-24A | NLT | 21.3" | 2048×1536 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
| Panel Size : | 6.5 inch |
| Dot Resolution : | 640(RGB)×480 (VGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 122 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.069×0.207 mm (H×V) |
| Pixel Pitch : | 0.207×0.207 mm (H×V) |
| Weight : | 240/260g (Typ./Max.) |
| Surface : | Clear, Hard coating (2H), Antireflection |
| Active Area : | 132.48×99.36 mm (H×V) |
| Bezel Area : | 141.5×105.6 mm (H×V) |
| Outline Dimension : | 178.8×126.8 mm (H×V) |
| Outline Depth : | 11.0±0.5 mm |
| Holes & Brackets : | Face mounting holes (4-Ф2.8) |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
NL6448BC20-14 Picture
