Product Details:
|
| Display Mode: | TN, Normally White, Transmissive | Active Area: | 408×306 Mm |
|---|---|---|---|
| Outline: | 448×348 Mm | Surface: | Antiglare, Hard Coating (3H) |
| Brightness: | 500 Cd/m² (Typ.) | Contrast Ratio: | 400:1 (Typ.) |
| High Light: | nec tft lcd,nec lcd screen |
||
NEC LCD Panel NL6448AC63-01 20.1 inch Normally White with 408×306 mm Active Area
What is Our Advantage?
1. We are the professional supplier of the industrial LCD Screen Replacements, located in the biggest components center of the world.
2. We can provide the one-stop purchase service.
3. Our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.
4. Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.
5. Fast delivery.
6. Reasonable price.
Our Services
Payment:
(1) Bank transfer , Western Union , T/T, Paypal are accepted.
(2) If any problem of payment, you can contact with us.
Shipment:
(1) Worldwide shipping. Any delivery way you want to choose, please contact us.
(2) All our LCD display will be shipped within1-3 days after confirmed full payment. Please inform us the price you want to mark on the invoice for the LCD screens.
(3) Please make sure your address is correct and deliverable by Express you choose. Your full name is recommended, especially Russian buyers.
(4) Delivery time is approximate:
------Via DHL, Fedex, UPS: 3-7working days
------Via EMS:7-15 working days
------Via Direct Express Line:1-3 working days.
NL6448AC63-01 Quick Details:
| Panel Brand : | NEC |
| Panel Model : | NL6448AC63-01 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 20.1 inch |
| Resolution : | 640(RGB)×480 , VGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 408×306 mm |
| Outline : | 448×348 mm |
| Surface : | Antiglare, Hard coating (3H) |
| Brightness : | 500 cd/m2 (Typ.) |
| Contrast Ratio : | 400:1 (Typ.) |
| Display Colors : | 16.2M (6-bit + FRC) , CIE1931 57% |
| Response Time : | 4/28 (Typ.)(Tr/Td) |
| Viewing Angle : | 65/65/55/50 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 12 pcs CCFL |
| Input Voltage : | 3.3V (Typ.) |
| Panel Size : | 20.1 inch |
| Dot Resolution : | 640(RGB)×480 (VGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 39 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.2125×0.6375 mm (H×V) |
| Pixel Pitch : | 0.6375×0.6375 mm (H×V) |
| Weight : | 1.90/2.06Kgs (Typ./Max.) |
| Surface : | Antiglare, Hard coating (3H) |
| Active Area : | 408×306 mm (H×V) |
| Bezel Area : | 413.0×311.0 mm (H×V) |
| Outline Dimension : | 448×348 mm (H×V) |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| NL6448HL11-02 | NLT | 3.5" | 640×480 |
| NL12876AC18-03KD | NLT | 10.6" | 1280×768 |
| NL12876AC18-03BD | NLT | 10.6" | 1280×768 |
| NL10276BC13-01BD | NLT | 6.5" | 1024×768 |
| NL10276BC28-27E | NLT | 14.1" | 1024×768 |
| NL10276BC28-24C | NLT | 14.1" | 1024×768 |
| NL2432HC22-30B | NLT | 3.5" | 240×320 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Details Picture for NL6448AC63-01
