Product Details:
|
| Resolution: | 320(RGB)×240 , QVGA | Input Voltage: | 3.3/5.0V (Typ.)(VCC) |
|---|---|---|---|
| Contrast Ratio: | 400:1 (Typ.) | Brightness: | 400 Cd/m² (Typ.) |
| Display Colors: | 262K (6-bit) , CIE1931 50% | Viewing Angle: | 65/65/40/65 (Typ.)(CR≥10) (L/R/U/D) |
| High Light: | nec tft lcd,nec lcd screen |
||
Antiglare 400 cd / m² NL3224AC35-20 NEC LCD Panel for Industrial Application
NL3224AC35-20 Information
| Panel Brand : | NEC |
| Panel Model : | NL3224AC35-20 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 5.5 inch |
| Resolution : | 320(RGB)×240 , QVGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 111.36×83.52 mm |
| Outline : | 134×104.5 mm |
| Surface : | Antiglare, Hard coating (3H), Antireflection |
| Brightness : | 400 cd/m² (Typ.) |
| Contrast Ratio : | 400:1 (Typ.) |
| Display Colors : | 262K (6-bit) , CIE1931 50% |
| Response Time : | 5/25 (Typ.)(Tr/Td) |
| Viewing Angle : | 65/65/40/65 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 2 pcs CCFL |
| Signal Interface : | CMOS (1 ch, 6-bit) , 33 pins |
| Input Voltage : | 3.3/5.0V (Typ.)(VCC) |
We Can Do for You:
1) One-to-one service with efficient & professional support;
2) Protection of your design and all your private information;
3) We could supply different hard disk for you.
4) Quality stability, can to provide certification of products;
5) Convenient payment methods: PayPal, T/T and Western Union;
6) Speedy shipment: we could arrange the shipment within 1-3 business days.
7) Quality & Service: Our priority has always been providing our clients with great quality products and superior customer service.
8) Unbeatable Prices: We continuously strive to find ways of reducing our production costs, and passing the savings to you.
Packaging & Delivery
· Delivery Lead Time :2~3 weeks
· Minimum Order :1 pcs LCD Panel
· Supply Ability :100 PCS / Per Day
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| ED0970C1 | E Ink | 9.7" | 1200×825 |
| ED097OC1 | E Ink | 9.7" | 1200×825 |
| ED080XC2 | E Ink | 8.0" | 1024×768 |
| ED080XC1 | E Ink | 8.0" | 1024×768 |
| ED060SC3 | E Ink | 6.0" | 800×600 |
| ED050SC1 | E Ink | 5.0" | 800×600 |
| PD035QX7 | E Ink | 3.5" | 320×240 |
| PW070DS6 | E Ink | 7.0" | 480×234 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
| Panel Size : | 5.5 inch |
| Dot Resolution : | 320(RGB)×240 (QVGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 72 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.116×0.348 mm (H×V) |
| Pixel Pitch : | 0.348×0.348 mm (H×V) |
| Surface : | Antiglare, Hard coating (3H), Antireflection |
| Active Area : | 111.36×83.52 mm (H×V) |
| Bezel Area : | 116.4×88.5 mm (H×V) |
| Outline Dimension : | 134×104.5 mm (H×V) |
| Outline Depth : | 12.5±0.5 mm |
| Holes & Brackets : | Rear mounting holes (4-M3) |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
NL3224AC35-20 NEC LCD Panel Picture
