Product Details:
|
| Panel Size :: | 17.0 Inch | Resolution :: | 1280(RGB)×1024 , SXGA |
|---|---|---|---|
| Active Area :: | 337.92×270.336 Mm | Outline :: | 404×322.2×21 Mm |
| Surface :: | Antiglare (Haze 25%), Hard Coating | Brightness :: | 230 Cd/m² (Typ.) |
| High Light: | tft lcd display,lcd display panel |
||
M170E1-01 Innolux 17.0 inch with 337.92×270.336 mm Active Area
M170E1-01 Specification
| Panel Size : | 17.0 inch |
|---|---|
| Dot Resolution : | 1280(RGB)×1024 (SXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 96 PPI |
| Aspect Ratio : | 5:4 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.088×0.264 mm (H×V) |
| Pixel Pitch : | 0.264×0.264 mm (H×V) |
| Weight : | 2.00/2.15Kgs (Typ./Max.) |
| Surface : | Antiglare (Haze 25%), Hard coating |
| Active Area : | 337.92×270.336 mm (H×V) |
| Bezel Area : | 342.0×274.4 mm (H×V) |
| Outline Dimension : | 404×322.2 mm (H×V) |
| Outline Depth : | 21.0 (Max.) mm |
| Holes & Brackets : | Face mounting holes (4-Φ3.4) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
| Display Mode : | TN, Normally White, Transmissive |
|---|---|
| Brightness : | 230 cd/m² (Typ.) |
| Contrast Ratio : | 300 : 1 (Typ.) (Transmissive) |
| Display Color : | 16.2M (6-bit + FRC) |
| Response Time : | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle : | 60/60/40/60 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | 6 o'clock |
| White Variation : | 1.25/1.40 (Typ./Max.)(5 points) |
| Sunlight Readable : |
N |
| Amount per Box : | 5 pcs |
|---|---|
| Box Size : | 534×316×462 mm (L×W×H) |
| Box Gross Weight : | 8.0 Kgs |
Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.
2. Great quality and high purity
Good quality is one secret for our success.
3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
