Product Details:
|
| Panel Brand: | NEC | Panel Model: | NL192108AC10-01D |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 9.0 Inch |
| Resolution: | 1920(RGB)×1080 , FHD | Display Mode: | UA-SFT, Normally Black, Transmissive |
| High Light: | nec tft lcd,nec lcd screen |
||
NL192108AC10-01D NEC LCD Panel 9.0 inch with 198.72×111.78 mm Active Area
The reasons you choose us
1).More competitive price! As a professional LCD Distributor, we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.
2).Great quality! All LCD Screen we sent are with good quality guarantee, 100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time, so we could promise save much more money on the shipping cost and better service is offered!
5).Best sale-service! Professional team to service with you before sale, on sale & after service.
NL192108AC10-01D Detail
| Panel Brand : | NEC |
| Panel Model : | NL192108AC10-01D |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 9.0 inch |
| Resolution : | 1920(RGB)×1080 , FHD |
| Display Mode : | UA-SFT, Normally Black, Transmissive |
| Active Area : | 198.72×111.78 mm |
| Outline : | 214.6×130×9.6 mm |
| Surface : | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| Brightness : | 400 cd/m² (Typ.) |
| Contrast Ratio : | 700:1 (Typ.) |
| Display Colors : | 262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 72% |
| Response Time : | 13/12 (Typ.)(Tr/Td) |
| Viewing Angle : | 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | WLED Embedded (LED Driver) |
| Signal Interface : | LVDS (2 ch, 6/8-bit) , 50 pins |
| Input Voltage : | 3.3V (Typ.) |
| Panel Size : | 9.0 inch |
| Dot Resolution : | 1920(RGB)×1080 (FHD) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 245 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0345×0.1035 mm (H×V) |
| Pixel Pitch : | 0.1035×0.1035 mm (H×V) |
| Weight : | 270/300g (Typ./Max.) |
| Surface : | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| Active Area : | 198.72×111.78 mm (H×V) |
| Bezel Area : | 201.8×114.8 mm (H×V) |
| Outline Dimension : | 214.6×130 mm (H×V) |
| Outline Depth : | 9.1±0.5 mm |
| Holes & Brackets : | Side mounting holes (4-M2) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
Our service
1. Agent Brand:
* Our sourcing line contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more bands tft lcd moulds from 2010, you can get the most competitive price for real products;
2. Quality to be guaranteed:
* All the panels are 100% original and brand new, no fake panels exists.Take the lcd screen from us, you can enjoy the real panels directly from original factory;
* Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the LCD panels packages have labels and serial number, you can check them;
* We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly.
* Products are sold to more than 20 countries.
* One year warranty .
6. The best TFT LCD solution:
*more tft lcd model detail information for the LCD screens including size, resolution, brightness, operating temperature or life time etc in our web site.
To get the latest prices, pls feel free to contact us.
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| ED060KG1 | E Ink | 6.0" | 1072×1448 |
| ED060KC1 | E Ink | 6.0" | 1072×1448 |
| ED060XC9 | E Ink | 6.0" | 758×1024 |
| ED060XD7 | E Ink | 6.0" | 758×1024 |
| ED080TC1 | E Ink | 8.0" | 1600×1200 |
| ED097TC1 | E Ink | 9.7" | 1200×825 |
| ET047TC1 | E Ink | 4.7" | 540×960 |
NL192108AC10-01D Picture
