Product Details:
|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 20.1 Inch |
|---|---|---|---|
| Resolution: | 1366(RGB)×768 , WXGA | Display Mode: | Super MVA, Normally Black, Transmissive |
| Active Area: | 444.633×249.984 Mm | Outline: | 473.3×276.7×37.5 Mm |
| High Light: | lcd display panel,innolux lcd screen |
||
Normally Black 20.1 inch V201B1-L03 Innolux LCD Panel with 444.633×249.984 mm
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| P101LCA-3P1 | Innolux | 10.1" | 1920×1200 |
| V650HP2-PS5 | Innolux | 65" | 1920×1080 |
| N156HGE-DB1 | Innolux | 15.6" | 1920×1080 |
| V500DJ4-QS1 | Innolux | 50" | 3840×2160 |
| V500DJ2-QS5 | Innolux | 50" | 3840×2160 |
| V400DJ1-QS5 | Innolux | 40" | 3840×2160 |
| P089DCZ-3A1 | Innolux | 8.9" | 800×1280 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Packing & Delivery for our LCD Screen Panel Replacements:
V201B1-L03 Information
| Panel Size : | 20.1 inch |
| Dot Resolution : | 1366(RGB)×768 (WXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 78 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.1085×0.3255 mm (H×V) |
| Pixel Pitch : | 0.3255×0.3255 mm (H×V) |
| Weight : | 1.95±0.1Kgs |
| Surface : | Antiglare, Hard coating (3H) |
| Active Area : | 444.633×249.984 mm (H×V) |
| Bezel Area : | 450.7×256.0 mm (H×V) |
| Outline Dimension : | 473.3×276.7 mm (H×V) |
| Outline Depth : | 28.05/37.5 (Typ./Max.) mm |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
| Display Mode : | Super MVA, Normally Black, Transmissive |
| Brightness : | 500 cd/m² (Typ.) |
| Contrast Ratio : | 1000 : 1 (Typ.) (Transmissive) |
| Display Color : | 16.2M (6-bit + FRC) |
| Color Gamut : | 75% NTSC (CIE1931) |
| Response Time : | 8 (Typ.)(G to G) |
| Viewing Angle : | 88/88/88/88 (Typ.)(CR≥20) (L/R/U/D) |
| Viewing Direction : | Symmetry |
| White color Chromaticity : | Wx:0.277; Wy:0.285 |
| White Variation : | 1.30 (Max.)(5 points) |
| Sunlight Readable : | N |
Packaging & Shipping for Our LCD panel
1. We will ship the LCD display panels within 1-3 workdays after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL and so some other direct international express line.
Other shipping terms can also be arranged according to specific requirements.
