4.8 inch SP12N002 KOE LCD Display Grade A+ LCD Panel industrial screen

4.8 inch SP12N002  KOE LCD Display  Grade A+ LCD Panel industrial screen
4.8 inch SP12N002  KOE LCD Display  Grade A+ LCD Panel industrial screen 4.8 inch SP12N002  KOE LCD Display  Grade A+ LCD Panel industrial screen

Large Image :  4.8 inch SP12N002 KOE LCD Display Grade A+ LCD Panel industrial screen

Product Details:
Place of Origin: Japan
Brand Name: KOE
Certification: ISO9001
Model Number: SP12N002
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: USD
Packaging Details: Standard packing
Delivery Time: 1-2days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,HKIN ESCROW .....
Supply Ability: 1000

4.8 inch SP12N002 KOE LCD Display Grade A+ LCD Panel industrial screen

Description
Product Number: SP12N002 Brand: KOE
Size Of Panel: 4.8" Resolution: 256×64
Brightness: 90
High Light:

anti glare lcd screen

,

digital lcd display

4.8 inch SP12N002 KOE LCD Display Grade A+ LCD Panel industrial screen



SP12N002 KOE LCD Display Optical Features:



Panel Brand : HITACHI
Panel Model : SP12N002
Panel Type : FSTN-LCD , LCM
Panel Size : 4.8 inch
Resolution : 256×64

Active Area : 120.29×30.05 mm
Outline : 160×68×12 mm
Surface : Hard coating (3H)
Brightness : 90 cd/m² (Typ.)
Contrast Ratio : 20:1 (Typ.)
Display Colors : Monochrome
Response Time : 110/160 (Typ.)(Tr/Td)



HITACHI SP12N002 Mechanical Features

Panel Size : 4.8 inch
Dot Resolution : 256×64
Pixel Configuration : Rectangle
Pixel Density : 54 PPI
Aspect Ratio : >3:1 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.470×0.470 mm (H×V)
Pixel Pitch : 0.470×0.470 mm (H×V)
Surface : Hard coating (3H)
Active Area : 120.29×30.05 mm (H×V)
Bezel Area : 124.3×34.05 mm (H×V)
Outline Dimension : 160×68 mm (H×V)
Outline Depth : 7.7/12.0 (Typ./Max.) mm
Holes & Brackets : Face mounting holes (4-Φ3.0)
Landscape or Portrait : Landscape type
Touch Panel : Without

What we do for SP12N002 :



As the leading LCD distributor in China, we are strong at EOL panels and hard to find panels of famous Brands such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE etc.

Our products lines are widely used on medical apparatus, industrial control facilities, portable electrical impedance measurement apparatus, digital video camera display, vehicle equipment, aerospace equipment. Our products mostly cover small sizes, like 1.5", 2.0", 2.2", 2.5", 3.0", 3.5", 4.0", 4.2", 4.3", 4.7", 5.0", 5.5", 5.7", 6.0", 6.4", 7.0", 8.0", 10.1", 10.4", 12.1", etc. Most of them are original factory sealed carton packing. Moreover, we will do the brightness inspection of them by testing board.



4.8 inch SP12N002  KOE LCD Display  Grade A+ LCD Panel industrial screen 0



4.8 inch SP12N002  KOE LCD Display  Grade A+ LCD Panel industrial screen 1



N&S will be your powerful partner on LCDs in China. Here we are to quote your need.
