Product Details:
|
| Panel Type :: | A-Si TFT-LCD , LCM | Resolution :: | 1440(RGB)×900 , WXGA+ |
|---|---|---|---|
| Active Area :: | 408.24×255.15 Mm | Surface :: | Antiglare (Haze 25%), Hard Coating (3H) |
| High Light: | tft lcd display,innolux lcd screen |
||
M190A1- L0A 19.0" LCM industrial flat panel display 1440×900 16.7M CCFL LVDS
| Panel Brand : | CMO |
|---|---|
| Panel Model : | M190A1-L0A |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 19.0 inch |
| Resolution : | 1440(RGB)×900 , WXGA+ |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 408.24×255.15 mm |
| Outline : | 428×278×17.6 mm |
| Surface : | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness : | 300 cd/m² (Typ.) |
| Contrast Ratio : | 1000:1 (Typ.) |
| Display Colors : | 16.7M (6-bit + Hi-FRC) , CIE1931 72% |
| Response Time : | 1.5/3.5 (Typ.)(Tr/Td) |
| Viewing Angle : | 85/85/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 4 pcs CCFL Without Driver |
| Signal Interface : | LVDS (2 ch, 8-bit) , 30 pins |
| Input Voltage : | 5.0V (Typ.) |
| Panel Size : | 19.0 inch |
|---|---|
| Dot Resolution : | 1440(RGB)×900 (WXGA+) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 89 PPI |
| Aspect Ratio : | 16:10 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0945×0.2835 mm (H×V) |
| Pixel Pitch : | 0.2835×0.2835 mm (H×V) |
| Weight : | 1.90/1.94Kgs (Typ./Max.) |
| Surface : | Antiglare (Haze 25%), Hard coating (3H) |
| Active Area : | 408.24×255.15 mm (H×V) |
| Bezel Area : | 412.2×259.2 mm (H×V) |
| Outline Dimension : | 428×278 mm (H×V) |
| Outline Depth : | 17.6 (Max.) mm |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
M190A1-L0A Innolux LCD Panel 19.0" LCM 1440×900 300 1000:1 16.7M CCFL LVDS
