SX25S004 10.0 inch KOE LCD Display with 202.775×152.075 mm Active Area

SX25S004 10.0 inch KOE LCD Display with 202.775×152.075 mm Active Area

SX25S004 10.0 inch  KOE LCD Display with 202.775×152.075 mm Active Area

Product Details:

Place of Origin: KOREA
Brand Name: KOE
Certification: ISO9001
Model Number: SX25S004

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: Western Union, T/T, MoneyGram, T/T
Supply Ability: 500PCS/DAY
Contact Now
Detailed Product Description
Panel Type: CSTN-LCD , LCM Panel Size: 10.0 Inch
Resolution: 800(RGB)×600 , SVGA Display Mode: STN, Normally Black, Transmissive
Active Area: 202.775×152.075 Mm Outline: 236×168×6.3 Mm

SX25S004 10.0 inch KOE LCD Display with 202.775×152.075 mm Active Area



SX25S004  Information



Panel Size : 10.0 inch
Dot Resolution : 800(RGB)×600 (SVGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 100 PPI
Aspect Ratio : 4:3 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0845×0.2535 mm (H×V)
Pixel Pitch : 0.2535×0.2535 mm (H×V)
Weight : 330g (Typ.)
Surface : Antiglare, Hard coating (3H)
Active Area : 202.775×152.075 mm (H×V)
Bezel Area : 207.0×156.0 mm (H×V)
Outline Dimension : 236×168 mm (H×V)
Outline Depth : 6.3 (Max.) mm
Landscape or Portrait : Landscape type
Touch Panel : Without



SX25S004 Information



Display Mode : STN, Normally Black, Transmissive
Brightness : 100 cd/m² (Typ.)
Contrast Ratio : 50 : 1 (Typ.) (Transmissive)
Display Color : Color ()
Response Time : 170/130 (Typ.)(Tr/Td)
Viewing Angle : 40 (Typ.)(CR≥2, Φ2-Φ1) (L/R/U/D)
Viewing Direction : 12 o'clock
White color Chromaticity : Wx:0.310; Wy:0.320
Sunlight Readable : N
