Brightness 250 Innolux LCD Panel AT035TN01 3.5 Inch LCM480×234 For Printer

Brightness 250 Innolux LCD Panel AT035TN01 3.5 Inch LCM480×234 For Printer

Brightness 250 Innolux LCD Panel AT035TN01 3.5 Inch LCM480×234 For Printer

Product Details:

Place of Origin: KOREA
Brand Name: Innolux
Certification: ISO9001
Model Number: AT035TN01

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500PCS/DAY
Contact Now
Detailed Product Description
Panel Brand: Innolux Panel Size: 3.5 Inch
Resolution: 480×234 Best View On: 6 O'clock
Weight: 34.5g (Typ.) Panel Type: A-Si TFT-LCD , LCM
Pixel Format: RGB Delta Touch Screen: Without

New and original AT035TN01 Innolux 3.5 inch LCM 480×234 Brightness 250 for Printer



Innolux AT035TN01 Mechanical Features



Panel Size : 3.5 inch
Pixel Features : Resolution Pixel Arrangement Dot Pitch (W×H) Pixel Pitch (W×H)
480×234 RGB Delta 0.150×0.216 mm -
Mechanical Size : Active Area (W×H) Bezel Area (W×H) Outline Dimension (W×H) Outline Depth
72×50.544 mm - 83×60.5 mm 4.5±0.3 mm
Outline Features : Form Style Aspect Ratio Orientation Shape Style
Flat Rectangle Display 7:5 (W : H) Landscape type -
Other Features : Panel Cover Weight Surface
- 34.5g (Typ.) -



Innolux AT035TN01 Optical Features

Basic Information : Brightness Operating Mode Contrast Ratio
250 cd/m² (Typ.) TN, Normally White, Transmissive 200:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
45/45/15/35 (Typ.)(CR≥10) 6 o'clock 20/30 (Typ.)(Tr/Td) (ms)



Innolux AT035TN01 Backlight Features

Backlight Features: Type Position Shape Amount  Life(Hours) Replacement
WLED Edge light type 1 string 4S1P 10K(Min.) -
WLED Electrical : Current Input Voltage Input Consumption
20mA (Typ.) 15V (Typ.)
Interface Features : Position Type WLED Driver
- Included in panel signal interface



Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.

2. Great quality and high purity
Good quality is one secret for our success.

3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
24/7 is available. Try our best to solve various problems customers encountered!



The reasons you choose us

1).More competitive price! As a professional LCD Distributor, we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.

2).Great quality! All LCD Screen we sent are with good quality guarantee, 100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time, so we could promise save much more money on the shipping cost and better service is offered!
5).Best sale-service! Professional team to service with you before sale, on sale & after service.





Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model Brand Size Resolution
N156BGE-PB1 Innolux 15.6" 1366×768
PP050IC-01F Innolux 5.0" 720×1280
P060DDZ-ZZ1 Innolux 6.0" 800×1280
ME236NA-01A Innolux 23.6" 1920×1080
F055A07-601 Innolux 5.5" 720×1280
F050A07-6T2 Innolux 5.0" 720×1280
V650HP1-PS6 Rev.C6 Innolux 65" 1920×1080
P101LCA-3P1 Innolux 10.1" 1920×1200
V650HP2-PS5 Innolux 65" 1920×1080
N156HGE-DB1 Innolux 15.6" 1920×1080
V500DJ4-QS1 Innolux 50" 3840×2160
V500DJ2-QS5 Innolux 50" 3840×2160
V400DJ1-QS5 Innolux 40" 3840×2160
P089DCZ-3A1 Innolux 8.9" 800×1280
N101JSA-P11 Innolux 10.1" 1200×1920
F050A13-601 Innolux 5.0" 720×1280



Quality Control:

  1. Visual Inspection

Make sure No damage, No Scratches, No dusty, No light leakage.

  1. Function Inspection

Make sure all functions are 100% tested ok
