Product Details:
|
| Manufacturer: | NLT | Model Name: | NL2432HC22-50A |
|---|---|---|---|
| Screen Size: | 3.5 Inch | View Direction: | 6 O'clock |
| Frame Rate: | 60Hz | Touch Panel: | Without |
| High Light: | nec tft lcd,nec lcd screen |
||
NL2432HC22-50A NLT 3.5 inch LCM 240×320 Brightness 220 for Handheld & PDA
Shipment for the LCD Display Panels:
1. Safe & Professional package for our LCD panels.
2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4. All our LCD panel will be tested pcs by pcs before been shipped out.
NL2432HC22-50A Information
| Panel Model | NL2432HC22-50A |
|---|---|
| Panel Brand | NEC |
| Descrition | a-Si TFT-LCD ,3.5 inch, 240×320 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transflective |
| Active Area | 53.64×71.52 mm |
| Outline | 63.5×85×5 mm |
| Surface | Clear, Hard coating (3H) |
| Contrast Ratio | 150:1 (Typ.)(Transmissive) 15:1 (Typ.)(Reflective) |
| Display Colors | 262K (6-bit) , CIE1931 40% |
| Response Time | 7/23 (Typ.)(Tr/Td) |
| Viewing Angle | 35/35/35/35 (Typ.)(CR＞5) (L/R/U/D) |
| Frequency | 60Hz |
Our Services
1. Quick and accurate reply with best service attidue to our business
2. Pofessional advise
3. Quick PI confirmation
4. Close production follow up and production process feedback
5. Safe package
6. Get feekback from your side when items arrived,
7. 24 months warranty for items
Why Choose US:
1. Prompt reply within 12 hours.
2. Understand inquiry in any language.
3. Products with top quality.
4. Very competitive prices.
5. 6-year experience in industrial LCD Screen replacements.
6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.
7. Fabulous after-sale service.
NL2432HC22-50A Basic Information
| Panel Model | NL2432HC22-50A |
|---|---|
| Panel Brand | NEC |
| Descrition | a-Si TFT-LCD ,3.5 inch, 240×320 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Vibration Resistance | 2.0G (19.6 m/s²) |
| Remarks | SR-NLT, left side 2 in 1 FPC (30mm) |
| Dot Resolution | 240(RGB)×320 (QVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 113 PPI |
| Aspect Ratio | 3:4 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0745×0.2235 mm (H×V) |
| Pixel Pitch | 0.2235×0.2235 mm (H×V) |
| Weight | 30/32g (Typ./Max.) |
| Surface | Clear, Hard coating (3H) |
| Active Area | 53.64×71.52 mm (H×V) |
| Bezel Area | 57.2×75.12 mm (H×V) |
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| NL204153BC21-09 | NLT | 21.3" | 2048×1536 |
| NL128102BC31-02 | NLT | 20.1" | 1280×1024 |
| NL8060BC26-28D | NLT | 10.4" | 800×600 |
| NL280210AM15-04A | NLT | 21.3" | 2800×2100 |
| NL2432HC22-50K | NLT | 3.5" | 240×320 |
| NL160120BC27-19E | NLT | 21.3" | 1600×1200 |
| NL204153BM21-05 | NLT | 21.3" | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3" | 2048×1536 |
Pls contact to us for more stock information
