Product Details:
|
| Panel Type: | LTPS TFT-LCD | Display Mode: | TN, Normally White, |
|---|---|---|---|
| Active Area: | 211.2×158.4 Mm | Outline: | 242×185 Mm |
| High Light: | industrial touch screen display,industrial lcd screen |
||
LT104AD18F00 TOSHIBA 10.4 inch 800×600 Descrition 211.2×158.4 mm Active Area
LT104AD18F00 Information
| Panel Model | LT104AD18F00 |
|---|---|
| Panel Brand | Toshiba Mobile Display |
| Descrition | LTPS TFT-LCD ,10.4 inch, 800×600 |
| Panel Type | LTPS TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 211.2×158.4 mm |
| Outline | 242×185 mm |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 8/17 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/50 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type | WLED |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins |
| Input Voltage | 3.3V (Typ.) |
LT104AD18F00 Basic Information
| Panel Model | LT104AD18F00 |
|---|---|
| Panel Brand | Toshiba Mobile Display |
| Descrition | LTPS TFT-LCD ,10.4 inch, 800×600 |
| Panel Type | LTPS TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Remarks | Mounting compatible with LTA104D182F series. |
