Product Details:
|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 2.2 Inch |
|---|---|---|---|
| Resolution: | 320(RGB)×320 | Display Mode: | TN, Normally White, Transmissive |
| Active Area: | 39.36×39.36 Mm | Outline: | 47.4×51.85 Mm |
| High Light: | lg display panel,lg lcd display |
||
LH220Q32-FD01 LG LCD Panel 2.2 inch Normally White with 39.36×39.36 mm Active Area
LH220Q32-FD01 Specification
| Panel Size : | 2.2 inch |
| Dot Resolution : | 320(RGB)×320 |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 206 PPI |
| Aspect Ratio : | 1:1 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.041×0.123 mm (H×V) |
| Pixel Pitch : | 0.123×0.123 mm (H×V) |
| Weight : | 18g (Typ.) |
| Surface : | Hard coating (3H) |
| Active Area : | 39.36×39.36 mm (H×V) |
| Outline Dimension : | 47.4×51.85 mm (H×V) |
| Outline Depth : | 3.5/3.8 (Typ./Max.) mm |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Embeded (4-wire Resistive) |
| Display Mode : | TN, Normally White, Transflective |
| Brightness : | 160 cd/m² (Typ.) |
| Contrast Ratio : | 120 : 1 (Typ.) (Transmissive) |
| Contrast Ratio : | 5:1 (Typ.) (Reflective) |
| Display Color : | 65K () |
| Color Gamut : | 45% NTSC (CIE1931) |
| Response Time : | 35 (Typ.)(Tr+Td) |
| Viewing Angle : | 45/45/40/50 (Typ.)(CR≥5) (L/R/U/D) |
| White color Chromaticity : | Wx:0.290; Wy:0.313 |
| White Variation : | 1.25 (Max.)(9 points) |
| Transmissivity : | 3.5% (Typ.)(with Polarizer) |
| Sunlight Readable : | Y |
