Product Details:
|
| Panel Size :: | 5.6 Inch | Active Area :: | 120.96×75.6 Mm |
|---|---|---|---|
| Brightness :: | 300 Cd/m² (Typ.) | Response Time :: | 70 (Max.)(Tr+Td) |
| High Light: | industrial touch screen display,industrial lcd panel |
||
LTD056EV7F00 TOSHIBA 5.6 inch for MID UMPC panel 1280×800 300 400:1 262K
LTD056EV7F00 Specification
| Panel Size : | 5.6 inch |
|---|---|
| Dot Resolution : | 1280(RGB)×800 (WXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 268 PPI |
| Aspect Ratio : | 16:10 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0315×0.0945 mm (H×V) |
| Pixel Pitch : | 0.0945×0.0945 mm (H×V) |
| Weight : | 61g (Typ.) |
| Surface : | Glare (Haze 0%) |
| Active Area : | 120.96×75.6 mm (H×V) |
| Bezel Area : | 125.7×80.3 mm (H×V) |
| Outline Dimension : | 147.5×96.05 mm (H×V) |
| Outline Depth : | 2.95/5.0 (Typ./Max.) mm |
| Holes & Brackets : | Face mounting holes (4-Φ2.2) on left, right up slugs |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
LTD056EV7F00 Specification
| Vertical Frequency : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Total Power Consumption : | 2.0W (Typ.) |
LTD056EV7F00 Specification
| Signal Category : | LVDS | |||||
|---|---|---|---|---|---|---|
| Signal Class : | LVDS (1 ch, 6-bit) | |||||
| Input Voltage for Panel : | 3.3V (Typ.) | |||||
| Input Current for Panel : | 230/350mA (Typ./Max.) | |||||
| Panel Power Consumption : | 2.0W (Typ.) | |||||
| Interface Type : | Connector | |||||
| Signal Interface : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| I-PEX | 20347-025E-02 | 0.4 mm | 25 pins | 1 pcs | ||
FAQ
1. Q: Where can I get the price?
A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
2. Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
3. Q: What about the lead time for mass production?
A: It depends on your order quantity and the season you place the order.
4. Q: What are your terms of payment?
A: We accept T/T, Western Union, MoneyGram, PayPal.
Our Services
Payment:
(1) Bank transfer , Western Union , T/T, Paypal are accepted.
(2) If any problem of payment, you can contact with us.
Shipment:
(1) Worldwide shipping. Any delivery way you want to choose, please contact us.
(2) All our LCD display will be shipped within1-3 days after confirmed full payment. Please inform us the price you want to mark on the invoice for the LCD screens.
(3) Please make sure your address is correct and deliverable by Express you choose. Your full name is recommended, especially Russian buyers.
(4) Delivery time is approximate:
------Via DHL, Fedex, UPS: 3-7working days
------Via EMS:7-15 working days
------Via Direct Express Line:1-3 working days.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LTA200A030F | TOSHIBA | 20.1" | 640×480 |
| LT121DEVBK00 | TOSHIBA | 12.1" | 1280×800 |
| LT121AC33W00 | TOSHIBA | 12.1" | 800×600 |
| LT121AC25500 | TOSHIBA | 12.1" | 1024×768 |
| LT104AD18E00 | TOSHIBA | 10.4" | 800×600 |
| LT104AD18900 | TOSHIBA | 10.4" | 800×600 |
| LT104AC36300 | TOSHIBA | 10.4" | 1024×768 |
| LT104AC36200 | TOSHIBA | 10.4" | 1024×768 |
| LT104AC36100 | TOSHIBA | 10.4" | 1024×768 |
| LT089AC29000 | TOSHIBA | 8.9" | 1280×768 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
