Product Details:
|
| Resolution: | 1920(RGB)×1200 , WUXGA | Operating Temperature: | 0 ~ 50 °C |
|---|---|---|---|
| Storage Temperature: | -20 ~ 60 °C | Size: | 17.1 Inch |
| Brightness: | 210cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) |
| Shape Style: | Wedge (PCBA Bent, Depth ≥5.2mm) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| High Light: | lg lcd display,lg replacement screen |
||
17.1 inch LP171WU8-SLB1 large screen monitor LG LCD Panel with 1920*1200
Product Information:
Panel Size : 17.1 inch
Dot Resolution : 1920(RGB)×1200 (WUXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 132 PPI
Aspect Ratio : 16:10 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.06375×0.19125 mm (H×V)
Pixel Pitch : 0.19125×0.19125 mm (H×V)
Weight : 800g (Typ.)
Surface : Antiglare, Hard coating (3H)
Active Area : 367.2×229.5 mm (H×V)
Bezel Area : 370.6×232.9 mm (H×V)
Outline Dimension : 382.2×247.5 mm (H×V)
Outline Depth : 7.0 (Max.) mm
Shape Style : Wedge (PCBA Bent, Depth ≥5.2mm)
Holes & Brackets : Side mounting holes (8-M2) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without
| Display Mode : | IPS, Normally Black, Transmissive |
| Brightness : | 210 cd/m² (Typ.) |
| Contrast Ratio : | 800 : 1 (Typ.) (Transmissive) |
| Display Color : | 1.07B (10-bit) |
| Response Time : | 30/15 (Typ.)(Tr/Td) |
| Viewing Angle : | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | Symmetry |
| White color Chromaticity : | Wx:0.313; Wy:0.329 |
| White Variation : | 1.40/1.60 (Typ./Max.)(13 points) |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LB060S01-FD01 | LG Display | 6.0" | 800×600 |
| LD470DUJ-SFE2 | LG Display | 47" | 1920×1080 |
| LC650EQK-FGK1 | LG Display | 65" | 3840×2160 |
| LH470M01-SH01 | LG Display | 4.7" | 540×960 |
| LH250Q01-TH03 | LG Display | 2.5" | 320×240 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
| Panel Brand : | LG Display |
| Panel Model : | LP171WU8-SLB1 |
| Panel Type : | a-Si TFT-LCD , Panel |
| Panel Size : | 17.1 inch |
| Resolution : | 1920(RGB)×1200 , WUXGA |
| Display Mode : | IPS, Normally Black, Transmissive |
| Active Area : | 367.2×229.5 mm |
| Outline : | 382.2×247.5×7 mm |
| Shape Style : | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface : | Antiglare, Hard coating (3H) |
| Brightness : | 210 cd/m² (Typ.) |
| Contrast Ratio : | 800:1 (Typ.) |
| Display Colors : | 1.07B (10-bit) |
| Response Time : | 30/15 (Typ.)(Tr/Td) |
| Viewing Angle : | 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | RGB LED Embedded (LED Driver) |
| Signal Interface : | LVDS (2 ch, 10-bit) , 50 pins |
| Input Voltage : | 3.3V (Typ.) |
We still have other LCD panel models and more in stock:
Sizes: 7.0, 8.9", 9.7", 10.0", 10.1", 10.2", 10.4", 11.1", 11.6", 12.1", 12.5", 13.1", 13.3", 14.0", 14.1", 14.5", 15.0" 15.4", 15.6", 16.0", 16.4", 17.0", 17.1", 17.3", 18.4"
Resolutions: XGA, WXGA, WXGA HD, , WXGA+, WXGA++, WSVGA, WUXGA, WUXGA+, WUXGA++, Full-HD
Backlight technologies: LED, SLIM LED, 1 CCFL, 2 CCFL
Brands: NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE and more.
