Product Details:
|
Panel Brand: | Kyocera | Panel Model: | SX14Q009-ZZA |
---|---|---|---|
Panel Size: | 5.7 Inch | Best View On: | 6 O'clock |
Display Colors: | Color | Frequency: | 70Hz |
Panel Weight: | 235g | Input Voltage: | 3.3V |
High Light: | industrial touch screen display,industrial lcd panel |
New and Original SX14Q009-ZZA KOE 5.7 inch LCM 320×240 160 for Industrial Application
SX14Q009-ZZA Specification
Panel Model | SX14Q009-ZZA |
---|---|
Panel Brand | HITACHI |
Descrition | CSTN-LCD ,5.7 inch, 320×240 |
Panel Type | CSTN-LCD |
Display Mode | STN, Normally Black, Transmissive |
Active Area | 115.18×86.38 mm |
Outline | 167×109×10.9 mm |
Contrast Ratio | 40:1 (Typ.) |
Display Colors | Color |
Response Time | 250/200 (Typ.)(Tr/Td) |
Viewing Angle | 45/45/40/40 (Typ.)(CR≥2) (L/R/U/D) |
Frequency | 70Hz |
Lamp Type | 3S5P WLED Without Driver |
Signal Interface | Parallel Data (8-bit) , 16 pins |
Input Voltage | 3.3V (Typ.) |
Dot Resolution | 320(RGB)×240 (QVGA) |
---|---|
Pixel Configuration | RGB Vertical Stripe |
Pixel Density | 70 PPI |
Aspect Ratio | 4:3 (H:V) |
Form Factor | Flat Rectangle Display |
Dot Pitch | 0.120×0.360 mm (H×V) |
Pixel Pitch | 0.360×0.360 mm (H×V) |
Weight | 235g (Typ.) |
Active Area | 115.18×86.38 mm (H×V) |
Bezel Area | 120.0×89.5 mm (H×V) |
Outline Dimension | 167×109 mm (H×V) |
Outline Depth | 10.4±0.5 mm |
Holes & Brackets | Face mounting holes (4-Φ3.5) |
Landscape or Portrait | Landscape type |
Touch Panel | Embeded (4-wire Resistive) |
Our Advantages
Below are our other LCD panels stock for your easy reference:
Panel Model | Brand | Size | Resolution |
KCS6448MSTT-X1 | Kyocera | 7.2" | 640×480 |
F-51430NFU-FW-AEN | Kyocera | 9.4" | 640×480 |
F-51430NFU-FW-AA | Kyocera | 9.4" | 640×480 |
KCL6448HSTT-X14 | Kyocera | 9.4" | 640×480 |
KCL6448HSTT-X12 | Kyocera | 9.4" | 640×480 |
KCS057QV1BM-G20 | Kyocera | 5.7" | 320×240 |
KCG047QV1AA-G02 | Kyocera | 4.7" | 320×240 |
KCG057QV1DB-G56 | Kyocera | 5.7" | 320×240 |
We also have other industrial LCD panels, pls contact to us for the further information:
Packaging & Delivery
· Delivery Lead Time :2~3 weeks
· Minimum Order :1 pcs LCD Panel
· Supply Ability :100 PCS / Per Day
