Product Details:
|
| Panel Brand: | Kyocera | Panel Model: | TCG121SVLPAANN-AN20 |
|---|---|---|---|
| Resolution: | 800×600 | Active Area: | 246×184.5 Mm |
| Contrast Ratio: | 1000:1 (Typ.) | Frequency: | 60Hz |
| High Light: | industrial touch screen display,industrial lcd panel |
||
Kyocera TCG121SVLPAANN-AN20 12.1 inch TFT LCD Module Kyocera with 278.3×207.5×10 mm Outline
TCG121SVLPAANN-AN20 Basic Information
| Panel Model | TCG121SVLPAANN-AN20 |
| Panel Brand | Kyocera |
| Descrition | a-Si TFT-LCD ,12.1 inch, 800×600 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
TCG121SVLPAANN-AN20 Mechanical Features
| Dot Resolution | 800(RGB)×600 (SVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 82 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.1025×0.3075 mm (H×V) |
| Pixel Pitch | 0.3075×0.3075 mm (H×V) |
| Weight | 645g |
| Surface | Antiglare |
| Active Area | 246×184.5 mm (H×V) |
| Bezel Area | 249.0×187.5 mm (H×V) |
| Outline Dimension | 278.3×207.5 mm (H×V) |
| Outline Depth | 9.5±0.5 mm |
| Holes & Brackets | Face mounting holes (4-Φ3.4, 3-R1.7) on left, right slugs |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
TCG121SVLPAANN-AN20 Optical Features
| Display Mode | TN, Normally White, Transmissive |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
| Display Color | 16.2M (6-bit + FRC) |
| Response Time | 4/22 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| White color Chromaticity | Wx:0.300; Wy:0.310 |
| Sunlight Readable | N |
Our Advantages
Packaging & Delivery
· Delivery Lead Time :2~3 weeks
· Minimum Order :1 pcs LCD Panel
· Supply Ability :100 PCS / Per Day
