Product Details:
|
| Panel Size: | 9.4 Inch | Panel Model: | NL6448AC30-09 |
|---|---|---|---|
| Panel Brand: | NEC | Active Area: | 192×144 Mm |
| Signal Interface: | CMOS (1 Ch, 4-bit) , 34 Pins | ||
| High Light: | nec tft lcd,nec lcd screen |
||
NL6448AC30-09 9.4 inch NLT LCD Display Panel Module 640×480 resolution Active Area 192×144 mm
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
Provide excellent LCD screen replacements with competitive price.
Safe, quick and efficient supply chain.
Plenty of stocks. Branded ones include LCD Screen panels for LG, Samsung, Sharp, BOE, Chimei and so on.
Your problems will be replied within 24 hours.
NL6448AC30-09 Basic Information
| Panel Model | NL6448AC30-09 |
| Panel Brand | NEC |
| Descrition | a-Si TFT-LCD ,9.4 inch, 640×480 |
| Panel Type | a-Si TFT-LCD |
NL6448AC30-09 Mechanical Features
| Dot Resolution | 640(RGB)×480 (VGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 84 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.10×0.30 mm (H×V) |
| Pixel Pitch | 0.30×0.30 mm (H×V) |
| Active Area | 192×144 mm (H×V) |
| Landscape or Portrait | Landscape type |
NL6448AC30-09 Optical Features
| Sunlight Readable | N |
NL6448AC30-09 Signal Interface
| Signal Category | TTL |
| Signal Class | CMOS (1 ch, 4-bit) |
| Interface Type | Connector |
| Signal Interface | JAE - IL-Z-10P-S125L3-E, Pitch:1.25 mm, Pin:10 pins |
