Product Details:
|
| Panel Type: | A-Si TFT-LCD | Panel Size: | 7.0 Inch |
|---|---|---|---|
| Resolution: | 800×480 | Contrast Ratio: | 250:1 (Typ.) |
| Display Colors: | 262K (6-bit) | Outline: | 163.4×106.1 Mm |
| High Light: | industrial touch screen display,industrial lcd screen |
||
LTA070B070F TFT LCD Module 7.0 inch, 800×480 Normally White, Transmissive 152.4×91.44 mm Active Area
LTA070B070F Specification
LTA070B070F Basic Information
| Panel Model | LTA070B070F |
| Panel Brand | Toshiba Matsushita |
| Descrition | a-Si TFT-LCD ,7.0 inch, 800×480 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -10 ~ 85 °C |
| Storage Temperature | -20 ~ 85 °C |
LTA070B070F Mechanical Features
| Dot Resolution | 800(RGB)×480 (WVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 133 PPI |
| Aspect Ratio | 15:9 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0635×0.1905 mm (H×V) |
| Pixel Pitch | 0.1905×0.1905 mm (H×V) |
| Weight | 95g (Typ.) |
| Active Area | 152.4×91.44 mm (H×V) |
| Outline Dimension | 163.4×106.1 mm (H×V) |
| Outline Depth | 1.89 (Typ.) mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
What’s our advantage compared with other suppliers?
(1). Before shipment, we will test every LCD Screen and ensure the quality.
(2). we provide high quality lcd panels for customers all over the world.
(3) .We have DBS, ISO9001 Certifications for our Panels.
(4) .Excellent service on before-sale, on-sale and after-sale.
Our service
1. Agent Brand:
* Our sourcing line contained but not limited to Samsung, LG, Sharp, AUO, Tianma, Chimei, Hannstar, Innolux, BOE and more bands tft lcd moulds from 2010, you can get the most competitive price for real products;
2. Quality to be guaranteed:
* All the panels are 100% original and brand new, no fake panels exists.Take the lcd screen from us, you can enjoy the real panels directly from original factory;
* Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the LCD panels packages have labels and serial number, you can check them;
3. Quickly delivery:
* We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly.
4. long-term partner:
* Products are sold to more than 20 countries.
5. Super After-Sale service:
* One year warranty .
6. The best TFT LCD solution:
*more tft lcd model detail information for the LCD screens including size, resolution, brightness, operating temperature or life time etc in our web site.
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| MT207FHB-N10 | BOE | 20.7" | 1920×1080 |
| LSC320HN08 | Samsung | 31.5" | 1920×1080 |
| H450VTN01.0 | AUO | 4.5" | 480×800 |
| LC430EGY-SHM1 | LG Display | 43" | 3840×2160 |
| LC600DUK-SGK1 | LG Display | 60" | 1920×1080 |
| V500DK1-QS1 | Innolux | 50" | 3840×2160 |
| CLAF050WG41 TXX | CPT | 5.0" | 720×1280 |
| CLAF050LN41 TXX | CPT | 5.0" | 540×960 |
| CLAN055WA41 3XB | CPT | 5.5" | 720×1280 |
| LH500WF4-SH01 | LG Display | 5.0" | 1080×1920 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Contact Person: savvy,ren
Tel: +8613302928193
