Product Details:
|
| Panel Model: | TM070DVHG01 | Panel Brand: | TIANMA |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD | Active Area: | 153.6×90 Mm |
| Outline: | 171.5×110.3 Mm | Frequency: | 60Hz |
| High Light: | lcd display white screen,lcd panel screen |
||
Normally White TM070DVHG01 7.0 inch 153.6×90 mm Active Area for 60Hz Frequency
We Can DO for You
1.Quality ensurance
100% original new and A grade,
You can enjoy the real panels directly from original factory;
2．Fast reply:
Our well-developed management system enables us to reply any kind of customers' inquiry in 24 hours.
3．Delivery ensurance:
Large Stock System, We have our own warehouses in Shenzhen and HongKong, with comprehensive supply lines.
4．After-Sale Service:
Professional support team to provide effective service, we are young and full of passion!
5. Professional acknowledgement of lcd panels industry to provide customers with effective advise.
We have been in original lcd panels industry for more than 6 years and know the main brands' lcd panel price system very well. What's more, we have our own engineer team to provide our customers guideline for choosing panels for their new projects.
6. Competitive quotation:
We are insistent in lcd panel industry. Our big customers network ensures us to provide large orders regularly for these original factories. What's more, our financial strength enables us to absorb large stock. All these make our price more and more competitive.
TM070DVHG01
| Panel Model | TM070DVHG01 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,7.0 inch, 1024×600 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 153.6×90 mm |
| Outline | 171.5×110.3 mm |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 16.7M (8-bit) , CIE1931 50% |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 75/75/70/75 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3S6P WLED Without Driver |
TM070DVHG01 Mechanical Features
| Dot Resolution | 1024(RGB)×600 (WSVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 169 PPI |
| Aspect Ratio | 17:10 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.050×0.150 mm (H×V) |
| Pixel Pitch | 0.150×0.150 mm (H×V) |
| Active Area | 153.6×90 mm (H×V) |
| Outline Dimension | 171.5×110.3 mm (H×V) |
| Outline Depth | 5.05 (Typ.) mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Embeded (Projected Capacitive Touch) |
