Product Details:
|
| Panel Type: | A-Si TFT-LCD , LCM | Panel Size: | 12.1 Inch |
|---|---|---|---|
| Resolution: | 1280(RGB)×800 , WXGA | Display Mode: | TN, Normally White, Transmissive |
| Active Area: | 261.12×163.2 Mm | Outline: | 283×185.1×19.9 Mm |
| High Light: | tft lcd panel,tft lcd display module |
||
12.1 inch AA121TA01 TFT LCD Module Mitsubishi Normally White for Industrial Application panel
AA121TA01 Information
| Panel Size : | 12.1 inch |
| Dot Resolution : | 1280(RGB)×800 (WXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 124 PPI |
| Aspect Ratio : | 16:10 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.068×0.204 mm (H×V) |
| Pixel Pitch : | 0.204×0.204 mm (H×V) |
| Weight : | 880g (Typ.) |
| Surface : | Antiglare, Hard coating (3H) |
| Active Area : | 261.12×163.2 mm (H×V) |
| Bezel Area : | 263.52×165.6 mm (H×V) |
| Outline Dimension : | 283×185.1 mm (H×V) |
| Outline Depth : | 19.4 (Typ.) mm |
| Holes & Brackets : | Side mounting holes (6-M3) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
| Display Mode : | TN, Normally White, Transmissive |
| Brightness : | 400 cd/m² (Typ.) |
| Contrast Ratio : | 600 : 1 (Typ.) (Transmissive) |
| Display Color : | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| Response Time : | 4/12 (Typ.)(Tr/Td) |
| Viewing Angle : | 80/80/60/70 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction : | 6 o'clock |
| White color Chromaticity : | Wx:0.313; Wy:0.329 |
| White Variation : | 1.30 (Max.)(5 points) |
| Sunlight Readable : | N |
Warranty:
1. All panels’ grade is promised strictly same as original factory’s standard.
2. All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.
3. We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.
4. ISO 9001 guarantee.
Our Advantages
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| AA141XB01 | Mitsubishi | 14.1" | 1024×768 |
| AA141XB00 | Mitsubishi | 14.1" | 1024×768 |
| AA141TA04--G1 | Mitsubishi | 14.1" | 1280×800 |
| AA141XA12 | Mitsubishi | 14.1" | 1024×768 |
| AA141XA11 | Mitsubishi | 14.1" | 1024×768 |
| AA141XA02 | Mitsubishi | 14.1" | 1024×768 |
| AA141XA01 | Mitsubishi | 14.1" | 1024×768 |
