Product Details:
|
| Panel Model: | KCG057QV1EA-G000 | Panel Brand: | Kyocera |
|---|---|---|---|
| Descrition: | 320×240 | Panel Type: | CSTN-LCD |
| Active Area: | 115.18×86.38 Mm | Outline: | 154.6×114.8×9 Mm |
| High Light: | medical lcd screen,medical lcd panel |
||
KCG057QV1EA-G000 Kyocera CSTN-LCD ,5.7 inch, 320×240 for 60Hz
| Panel Model | KCG057QV1EA-G000 |
|---|---|
| Panel Brand | Kyocera |
| Descrition | CSTN-LCD ,5.7 inch, 320×240 |
| Panel Type | CSTN-LCD |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -20 ~ 60 °C |
Shipment for the LCD Display Panels:
1. Safe & Professional package for our LCD panels.
2. We can ship to you by UPS/FEDEX/DHL/TNT and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.
4. All our LCD panel will be tested pcs by pcs before been shipped out.
| Dot Resolution | 320(RGB)×240 (QVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 70 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.120×0.360 mm (H×V) |
| Pixel Pitch | 0.360×0.360 mm (H×V) |
| Weight | TBD |
| Surface | Glare (Haze 0%) |
| Active Area | 115.18×86.38 mm (H×V) |
| Bezel Area | 117.2×88.4 mm (H×V) |
| Outline Dimension | 154.6×114.8 mm (H×V) |
| Outline Depth | 8.5±0.5 mm |
| Holes & Brackets | Face mounting holes (2-Φ3.0, 2-R1.6) on left, right bezel |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Guarantee:
(1) All items will be strictly tested and shipped with safe & professional package.
(2) We have 2~6months warranty for every LCD screen panels, depend on the different LCD panel models.
(3) We will do our best to solve any possible problem for your after sale. Please contact to us
| Display Mode | STN, Normally Black, Transmissive |
|---|---|
| Brightness | 250 cd/m² (Typ.) |
| Contrast Ratio | 55 : 1 (Typ.) (Transmissive) |
| Display Color | Color () |
| Response Time | 180/170 (Typ.)(Tr/Td) |
| Viewing Angle | 50/50/20/35 (Typ.)(CR≥2) (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| White color Chromaticity | Wx:0.310; Wy:0.330 |
| Sunlight Readable | N |
Packing& Shipping:
Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
Guarantee:
(1) All items will be strictly tested and shipped with strong package.
(2) We have 3~6months warranty for every item, depend on the different item.
(3) We will do our best to solve any possible problem for your after sale. Please contact with us.
KCG057QV1EA-G000 Kyocera CSTN-LCD ,5.7 inch, 320×240 for 60Hz
| Vertical Frequency | 75Hz |
|---|---|
| Reverse Scan | No |
| Driving Method | Duty: 1/240 |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| KCS072VG1MJ-G40 | Kyocera | 7.2" | 640×480 |
| KCS6448MSTT-X1 | Kyocera | 7.2" | 640×480 |
| F-51430NFU-FW-AEN | Kyocera | 9.4" | 640×480 |
| F-51430NFU-FW-AA | Kyocera | 9.4" | 640×480 |
| KCL6448HSTT-X14 | Kyocera | 9.4" | 640×480 |
| KCL6448HSTT-X12 | Kyocera | 9.4" | 640×480 |
| KCS057QV1BM-G20 | Kyocera | 5.7" | 320×240 |
| KCG047QV1AA-G02 | Kyocera | 4.7" | 320×240 |
We also have other industrial LCD panels, pls contact to us for the further information
KCG057QV1EA-G000 pictures
