Product Details:
|
| Series: | LQ084V3DG | Keywords Desc.: | SHARP 8.4" TN LCM 640×480 400nits WLED TTL 33pins |
|---|---|---|---|
| Product Class: | Graphic LCD Display | Product Tags: | Color TFT-LCD,Wide Temperature LCD,Transmissive LCD |
| Application: | Industrial Application | Panel Type: | A-Si TFT-LCD |
| Panel Composition: | LCM | Panel Size: | 8.4" |
| Resolution: | 640×480 | Aspect Ratio: | 4:3 (W:H) |
| Form Factor: | Flat Rectangle Display | Orientation: | Landscape Type |
| Active Area: | 170.88 (W) × 128.16 (H) Mm (A.A) | Viewing Area: | 175.5 (W) × 133.0 (H) Mm (V.A) |
| Outline Dimension: | 199.5 (W) × 149.5 (H) Mm | Weight: | 400g (Max.) |
| LC Family: | TN | Polarizer: | Transmissive |
| Brightness: | 400 (Typ.) | Contrast Ratio: | 600:1 (Typ.) |
| High Light: | sharp lcd screen,sharp lcd flat screen |
||
8.4 inch SHARP LQ084V3DG02 TN LCM 640×480 400nits WLED TTL 33pins
LQ084V3DG02 Main Parameters
| Panel Brand : | SHARP |
| Panel Model : | LQ084V3DG02 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 8.4 inch |
| Resolution : | 640(RGB)×480 , VGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 170.88×128.16 mm |
| Outline : | 199.5×149.5 mm |
| Surface : | Antiglare |
| Brightness : | 400 cd/m2 (Typ.) |
| Contrast Ratio : | 600:1 (Typ.) |
| Display Colors : | 262K (6-bit) |
| Response Time : | 5/21 (Typ.)(Tr/Td) |
| Viewing Angle : | 65/65/55/60 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type : | 6S2P WLED |
| Signal Interface : | Parallel RGB (1 ch, 6-bit) , 33 pins |
| Input Voltage : | 3.3V (Typ.)(VCC) |
Our Company Strength in LCD Screen Sourcing:
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange
professional sales team to follow up your case.
| Panel Size : | 8.4 inch |
| Dot Resolution : | 640(RGB)×480 (VGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 95 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.089×0.267 mm (H×V) |
| Pixel Pitch : | 0.267×0.267 mm (H×V) |
| Weight : | 400g (Max.) |
| Surface : | Antiglare |
| Active Area : | 170.88×128.16 mm (H×V) |
| Bezel Area : | 175.5×133.0 mm (H×V) |
| Outline Dimension : | 199.5×149.5 mm (H×V) |
| Outline Depth : | 11.6 (Typ.) mm |
| Holes & Brackets : | Face mounting holes (4-Φ3.2) |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| LQ055T3SX04 | SHARP | 5.5" | 1080×1920 |
| LQ079L1SX06 | SHARP | 7.9" | 1536×2048 |
| LQ079L1SX04 | SHARP | 7.9" | 1536×2048 |
| LQ133M1JW08 | SHARP | 13.3" | 1920×1080 |
| LQ156D1JX02 | SHARP | 15.6" | 3840×2160 |
LQ084V3DG02 Picture
