1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness

1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness
1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness 1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness 1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness 1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness

Large Image :  1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness

Product Details:
Place of Origin: Japan/Taiwan
Brand Name: Industrial LCD Displays
Certification: ISO9001
Model Number: LTL106HL01-001
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
Delivery Time: 1-3 Working Days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 1000 PCS PER DAY

1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness

Description
Outline: 246.52×149.02×5.2 Mm Resolution: 1920(RGB)×1080 , FHD
Display Mode: PLS, Normally Black, Transmissive Active Area: 234.72×132.03 Mm
Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) Panel Size: 10.6 Inch
Brightness: 400 Cd/m² (Typ.) Surface: Glare (Haze 0%), Hard Coating (2H)
High Light:

industrial lcd screen

,

industrial lcd panel

1920*1080 LTL106HL01-001 industrial lcd screen 10.6 inch High brightness



Below are our other LCD panels stock for your easy reference:

Panel Model Brand Size Resolution
G121IJ1-P01 Innolux 12.1" 1280×800
F04307-06Z Innolux 4.3" 480×800
CG043JN16 Innolux 4.3" 480×800
F04008-01U Innolux 4.0" 480×800
N156BGE-P21 Innolux 15.6" 1366×768
F04801-01Z Innolux 4.8" 540×960

We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk





General Features

Panel Brand : SAMSUNG
Panel Model : LTL106HL01-001
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 10.6 inch
Resolution : 1920(RGB)×1080 , FHD
Display Mode : PLS, Normally Black, Transmissive
Active Area : 234.72×132.03 mm
Outline : 246.52×149.02×5.2 mm
Surface : Glare (Haze 0%), Hard coating (2H)
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 800:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 50%
Response Time : 16 (Typ.)(Tr+Td)
Viewing Angle : 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 9S4P WLED Embedded (LED Driver)
Signal Interface : LVDS (2 ch, 8-bit) , 51 pins
Input Voltage : 3.3V (Typ.)



Basic Information

Panel Model : LTL106HL01-001
Panel Type : a-Si TFT-LCD , Panel
Operating Temperature : 0 ~ 50 °C
Storage Temperature : -20 ~ 60 °C



Panel Size : 10.6 inch
Dot Resolution : 1920(RGB)×1080 (FHD)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 207 PPI
Aspect Ratio : 16:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.04075×0.12225 mm (H×V)
Pixel Pitch : 0.12225×0.12225 mm (H×V)
Weight : 193g (Max.)
Surface : Glare (Haze 0%), Hard coating (2H)
Active Area : 234.72×132.03 mm (H×V)
Bezel Area : 238.59×135.73 mm (H×V)
Outline Dimension : 246.52×149.02 mm (H×V)
Outline Depth : 2.74/5.2 (Typ./Max.) mm
Holes & Brackets : Without
Landscape or Portrait : Landscape type
Touch Panel : Without

Optical Features

Display Mode : PLS, Normally Black, Transmissive
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 800 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (8-bit)
Color Gamut : 50% NTSC (CIE1931)
Response Time : 16 (Typ.)(Tr+Td)
Viewing Angle : 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.313; Wy:0.329
White Variation : 1.43 (Max.)(13 points)



Backlight System

Lamp Position : Edge light type
Lamp Type : WLED
Lamp Amount : 9S4P
Lamp Shape : Array
Lamp Life Time : 12K(Min.) (Hours)
Interface Type : Included in panel signal interface
Lamp Driver Board : Embedded (LED Driver)
Lamp Driver Board : 5.3/21.0V (Min./Max.)



Our guarantee:

(1) Our all LCD screen will be strictly tested pcs by pcs and shipped with professional & safe package.

(2) We have 12 months warranty for each LCD display, depend on the different items.

(3) We will do our best to solve any possible problem of our LCD panels for your after sale. Please contact with us if any needs.



We still have other LCD panel models and more in stock:
Sizes: 7.0, 8.9", 9.7", 10.0", 10.1", 10.2", 10.4", 11.1", 11.6", 12.1", 12.5", 13.1", 13.3", 14.0", 14.1", 14.5", 15.0" 15.4", 15.6", 16.0", 16.4", 17.0", 17.1", 17.3", 18.4"
Resolutions: XGA, WXGA, WXGA HD, , WXGA+, WXGA++, WSVGA, WUXGA, WUXGA+, WUXGA++, Full-HD
Backlight technologies: LED, SLIM LED, 1 CCFL, 2 CCFL

Brands: NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE and more.
