Product Details:
|
| Panel Model: | A070FW01-1 | Panel Brand: | AUO |
|---|---|---|---|
| Size: | 7.0 Inch | Panel Type: | A-Si TFT-LCD |
| Display Mode: | TN, Normally White | Active Area: | 154.08×86.58 Mm |
| Display Colors: | Full Color | Frequency: | 60Hz |
| High Light: | car lcd display,car lcd panel |
||
A070FW01-1 AUO 7 inch LCM 400×234 400 150:1 Full color
A070FW01-1 Information
| Panel Model | A070FW01-1 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,7.0 inch, 400×234 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 154.08×86.58 mm |
| Outline | 166×100 mm |
| Surface | |
| Contrast Ratio | 150:1 (Typ.) |
| Display Colors | Full color |
| Response Time | 25/30 (Typ.)(Tr/Td) |
| Viewing Angle | 50/50/15/35 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcs CCFL Without Driver |
| Signal Interface | TFT Specific Analog RGB , 26 pins |
| Input Voltage | 5.0//5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Panel Model | A070FW01-1 |
|---|---|
| Panel Brand | AUO |
| Descrition | a-Si TFT-LCD ,7.0 inch, 400×234 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -30 ~ 70 °C |
| Storage Temperature | -30 ~ 85 °C |
| Display Mode | TN, Normally White, Transmissive |
|---|---|
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 150 : 1 (Typ.) (Transmissive) |
| Display Color | Full color () |
| Response Time | 25/30 (Typ.)(Tr/Td) |
| Viewing Angle | 50/50/15/35 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| White color Chromaticity | Wx:0.310; Wy:0.330 |
| Sunlight Readable | N |
Our Service
• Long lasting product cycle for continuity thru all phases of project rollouts and servicing
• Competitive price for different brands hard disk.
• Mass stock with the better price.
• Multiple options.
• Warranty service.
• Better team to provide the before-sales, on-sale and after-sale service
• Pls send us message if any hard disk needed.
Up to now, over hundreds of aerospace, power management, network, communications, instrumentation and consumer electronics, etc are benefiting from our service and LCD screen panels.
We can do for you:
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| H598QAN01.0 | AUO | 6.0" | 1440×2560 |
| T430HVN01.2 CELL | AUO | 43" | 1920×1080 |
| H495TAN01.2 | AUO | 5.0" | 720×1280 |
| T650QVN04.5 CELL | AUO | 65" | 3840×2160 |
| M320DVN01.0 CELL | AUO | 32.0" | 2560×1440 |
| M238HVN01.0 CELL | AUO | 23.8" | 1920×1080 |
| M238HVN01.2 CELL | AUO | 23.8" | 1920×1080 |
| T320XVN02.F CELL | AUO | 31.5" | 1366×768 |
| T430HVN01.6 CELL | AUO | 43" | 1920×1080 |
| B101EAN01.2 CELL | AUO | 10.1" | 1280×800 |
| H497EAN01.0 | AUO | 5.0" | 768×1280 |
We also have other industrial LCD panels, pls contact to us for the further information
