Product Details:
|
| Panel Model: | A035VL01 V6 | Panel Brand: | AUO |
|---|---|---|---|
| Size: | 3.5 Inch | Panel Type: | LTPS TFT-LCD |
| Active Area: | 75.6×45.36 Mm | Outline: | 86.1×51.66 Mm |
| Contrast Ratio: | 800:1 (Typ.) | Frequency: | 60Hz |
| High Light: | car lcd panel,vehicle lcd display |
||
A035VL01 V6 AUO 3.5 inch LCM 800×480 Brightness 315 800:1 for Procket TV
A035VL01 V6 Information
| Panel Model | A035VL01 V6 |
|---|---|
| Panel Brand | AUO |
| Descrition | LTPS TFT-LCD ,3.5 inch, 800×480 |
| Panel Type | LTPS TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 75.6×45.36 mm |
| Outline | 86.1×51.66 mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 15/30 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 5S1P WLED Without Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI , 70 pins |
| Input Voltage | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Panel Model | A035VL01 V6 |
|---|---|
| Panel Brand | AUO |
| Descrition | LTPS TFT-LCD ,3.5 inch, 800×480 |
| Panel Type | LTPS TFT-LCD |
| Model Alias | A035VL01 V.6 |
| Operating Temperature | -10 ~ 60 °C |
| Storage Temperature | -25 ~ 70 °C |
| Dot Resolution | 800(RGB)×480 (WVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 268 PPI |
| Aspect Ratio | 15:9 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0315×0.0945 mm (H×V) |
| Pixel Pitch | 0.0945×0.0945 mm (H×V) |
| Weight | 25±2.5g |
| Surface | Glare (Haze 0%) |
| Active Area | 75.6×45.36 mm (H×V) |
| Bezel Area | 77.9×47.76 mm (H×V) |
| Outline Dimension | 86.1×51.66 mm (H×V) |
| Outline Depth | 2.545±0.15 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
