Product Details:
|
| Panel Type: | FSTN-LCD , LCM | Panel Size: | 5.7 Inch |
|---|---|---|---|
| Resolution: | 320×240 , QVGA | Display Mode: | STN, Black/White (Negative), Transmissive |
| Active Area: | 115.18×86.38 Mm | Outline: | 144×104.8×13.2 Mm |
| High Light: | industrial touch screen display,industrial lcd panel |
||
Monochrome Kyocera Industrial Flat Panel Display KG057QVLCD-G000 5.7 inch
KG057QVLCD-G000 Main Parameters
| Panel Brand : | Kyocera |
| Panel Model : | KG057QVLCD-G000 |
| Panel Type : | FSTN-LCD , LCM |
| Panel Size : | 5.7 inch |
| Resolution : | 320×240 , QVGA |
| Display Mode : | STN, Black/White (Negative), Transmissive |
| Active Area : | 115.18×86.38 mm |
| Outline : | 144×104.8×13.2 mm |
| Surface : | Glare (Haze 0%) |
| Brightness : | 300 cd/m2 (Typ.) |
| Contrast Ratio : | 10:1 (Typ.) |
| Display Colors : | Monochrome |
| Response Time : | 380/120 (Typ.)(Tr/Td) |
| Viewing Angle : | 45/45/20/40 (Typ.)(CR≥2) (L/R/U/D) |
| Frequency : | 75Hz |
| Lamp Type : | WLED |
| Signal Interface : | Parallel Data (4-bit) , 20 pins |
FAQ
Q1: Can I place sample order first?
A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
Q2: How could I pay them?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: How to place the order?
A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.
Q4: How long can I get my order?
A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.
Q5: How to send us the products?
A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.
Packaging & Delivery
Packaging Details:
Antistatic bag + Bubble bag + Foam box + Carton box
Delivery Detail:
1-3 working days after payment confirmed
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| KCS072VG1MJ-G40 | Kyocera | 7.2" | 640×480 |
| KCS6448MSTT-X1 | Kyocera | 7.2" | 640×480 |
| F-51430NFU-FW-AEN | Kyocera | 9.4" | 640×480 |
| F-51430NFU-FW-AA | Kyocera | 9.4" | 640×480 |
| KCL6448HSTT-X14 | Kyocera | 9.4" | 640×480 |
| KCL6448HSTT-X12 | Kyocera | 9.4" | 640×480 |
| KCS057QV1BM-G20 | Kyocera | 5.7" | 320×240 |
| KCG047QV1AA-G02 | Kyocera | 4.7" | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7" | 320×240 |
| KCB104VG2CG-G20 | Kyocera | 10.4" | 640×480 |
| KS3224ASTT-FW-X13 | Kyocera | 5.7" | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7" | 320×240 |
| KCS6448BSTT-X1 | Kyocera | 10.4" | 640×480 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
| Panel Size : | 5.7 inch |
| Dot Resolution : | 320×240 (QVGA) |
| Pixel Configuration : | Rectangle |
| Pixel Density : | 70 PPI |
| Aspect Ratio : | 4:3 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.360×0.360 mm (H×V) |
| Pixel Pitch : | 0.360×0.360 mm (H×V) |
| Weight : | 175g (Typ.) |
| Surface : | Glare (Haze 0%) |
| Active Area : | 115.18×86.38 mm (H×V) |
| Bezel Area : | 119.4×90.6 mm (H×V) |
| Outline Dimension : | 144×104.8 mm (H×V) |
KG057QVLCD-G000 Picture
