Product Details:
|
| Panel Size :: | 27.0 Inch | Resolution :: | 1920(RGB)×1200 , WUXGA |
|---|---|---|---|
| Active Area :: | 581.76×363.6 Mm | Display Colors :: | 16.7M (8-bit) , CIE1931 92% |
| High Light: | samsung lcd screen,samsung lcd display panel |
||
LTM270M1-L01 Samsung 27.0 inch 1920×1200 500 Normally Black 60Hz
LTM270M1-L01 Information
| Panel Size : | 27.0 inch |
|---|---|
| Dot Resolution : | 1920(RGB)×1200 (WUXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 83 PPI |
| Aspect Ratio : | 16:10 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.101×0.303 mm (H×V) |
| Pixel Pitch : | 0.303×0.303 mm (H×V) |
| Weight : | 3.80Kgs (Max.) |
| Surface : | Antiglare (Haze 44%), Hard coating (3H) |
| Active Area : | 581.76×363.6 mm (H×V) |
| Bezel Area : | 586.8×368.6 mm (H×V) |
| Outline Dimension : | 615.8×397.6 mm (H×V) |
| Outline Depth : | 41.6 (Typ.) mm |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
LTM270M1-L01 Information
| Lamp Position : | Direct light type | |||||
|---|---|---|---|---|---|---|
| Lamp Type : | CCFL | |||||
| Lamp Amount : | 16 pcs | |||||
| Lamp Shape : | Straight | |||||
| Lamp Life Time : | 30K(Min.) (Hours) | |||||
| Lamp Voltage : | 1050V (Typ.) | |||||
| Lamp Current : | 6.0±1.0mA | |||||
| Lamp Operating Frequency : | 60±10KHz | |||||
| Lamp Startup Voltage : | 1520/1910V (Max.)(Ta=+25/0℃) | |||||
| Interface Type : | Connector | |||||
| Backlight Interface | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| YEONHO | 20022WR-14L | 2.0 mm | 14 pins | 1 pcs | ||
| Lamp Driver Board : | Embedded (Inverter) | |||||
| Lamp Driver Board : | 24.0±2.4V | |||||
After-sale Services:
1)warranty for 1 year, 7 days return for the non-working items, except broken, crashed cargo (Buyer pay for return shipping fee).
2)Please make sure the item is compatible for your model before ordering. No return for incompatible issues.
3)When you receive the item,if you find the box is break and the goods break. Please take photo about the goods and refuse accepting the goods .Please contact me and sent photo of product to me as soon as possible .I will complaint the delivery company.
We ensure offer great products, services and the most favorable prices. And we have a long-term and reliable supply. If you have any questions, suggestions or need any assistance, we are always here to give you quick response.
Packaging & Shipping for Our LCD panel
1. We will ship the LCD display panels within 1-3 workdays after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL and so some other direct international express line.
Other shipping terms can also be arranged according to specific requirements.
