Product Details:
|
| Panel Type :: | A-Si TFT-LCD , LCM | Display Mode :: | TN, Normally White, Transmissive [[Panelook Copyright, Copy Is Strictly Prohibited] IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA |
|---|---|---|---|
| Active Area :: | 409.8×230.4 Mm | Surface :: | Antiglare (Haze 25%), Hard Coating (3H) |
| Display Colors :: | 16.7M (8-bit) , CIE1931 72% | Signal Interface :: | LVDS (1 Ch, 8-bit) , 30 Pins |
| High Light: | samsung lcd screen,samsung lcd display panel |
||
LTA185AT01 Samsung 18.5 inch 1366×768 230 800:1 Normally White Active Area
Here comes our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| LSC550FJ04-W | Samsung | 55" | 3840×2160 |
| LSC550FJ03-W | Samsung | 55" | 3840×2160 |
| LSC490HN03-W | Samsung | 49" | 1920×1080 |
| LSC650FJ10-W | Samsung | 65" | 3840×2160 |
| LSC490HN04-W | Samsung | 49" | 1920×1080 |
| LSC400HM15-W | Samsung | 40" | 1920×1080 |
| LSM315HP02-M01 | Samsung | 31.5" | 1920×1080 |
Pls contact to us for more stock information: salespm@nselectronic.com.hk
LTA185AT01 Specification
| Panel Size : | 18.5 inch |
|---|---|
| Dot Resolution : | 1366(RGB)×768 (WXGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 84 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.100×0.300 mm (H×V) |
| Pixel Pitch : | 0.300×0.300 mm (H×V) |
| Weight : | 1.40Kgs (Typ.) |
| Surface : | Antiglare (Haze 25%), Hard coating (3H) |
| Active Area : | 409.8×230.4 mm (H×V) |
| Bezel Area : | 413.8×234.4 mm (H×V) |
| Outline Dimension : | 430.4×254.6 mm (H×V) |
| Outline Depth : | 8.3/10.7 (Typ./Max.) mm |
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
Warranty:
1. All panels’ grade is promised strictly same as original factory’s standard.
2. All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.
3. We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.
4. ISO 9001 guarantee.
LTA185AT01 Specification
| Lamp Position : | Edge light type (Right side) | |||||
|---|---|---|---|---|---|---|
| Lamp Type : | WLED | |||||
| Lamp Amount : | 21S1P | |||||
| Lamp Shape : | 1 string | |||||
| Lamp Life Time : | 30K(Min.) (Hours) | |||||
| Lamp Voltage : | 67.79±3.74V | |||||
| Lamp Current : | 120mA (Typ.) | |||||
| Lamps Power Consumption : | 8.13W (Typ.) | |||||
| Interface Type : | Connector | |||||
| Interface Position : | ||||||
| Backlight Interface | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| molex | 104086-0410 | 1.25 mm | 4 pins | 1 pcs | BLE-4PINS-AACC | |
| Lamp Driver Board : | No | |||||
