Product Details:
|
| Product Number: | G170EG01 V1 | Brand: | AUO |
|---|---|---|---|
| Size Of Panel: | 17.0" | Resolution: | 1280×1024 |
| C/R: | 800:1 | Backlight: | WLED |
| Brightness: | 380 | Interface: | LVDS |
| High Light: | auo lcd screen,auo lcd display |
||
AUO LCD Panel G170EG01 V1 17.0" LCD Panel Display 1280 RGB* 1024 SXGA
| Panel Brand : | AUO |
|---|---|
| Panel Model : | G170EG01 V1 |
| Model Alias : | G170EG01 V.1 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Application : | Mobile Machine |
| Operating Temperature : | -30 ~ 85 °C |
| Storage Temperature : | -30 ~ 85 °C |
| RoHS : | ROHS |
Panel Size : 17.0 inch
Dot Resolution : 1280(RGB)×1024 (SXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 96 PPI
Aspect Ratio : 5:4 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.088×0.264 mm (H×V)
Pixel Pitch : 0.264×0.264 mm (H×V)
Weight : 1.35Kgs (Typ.)
Surface : Antiglare, Hard coating (3H)
Active Area : 337.92×270.336 mm (H×V)
Bezel Area : 341.6×274.0 mm (H×V)
Outline Dimension : 358.5×296.5 mm (H×V)
Outline Depth : 18.0 (Max.) mm
Holes & Brackets : Side mounting holes (4-M3) on left, right bezel
Landscape or Portrait : Landscape type
Touch Panel : Without
