Product Details:
|
| Product Number: | G104SN03 V5 | Brand: | AUO |
|---|---|---|---|
| Size Of Panel: | 10.4" | Resolution: | 800×600 |
| Brightness: | 230 Cd/m² | C/R: | 500:1 |
| High Light: | auo lcd screen,auo lcd display |
||
High Quality VGA LCD Controller Board RT2270C A work for 10.4inch G104SN03 V5 800*600 lcd panel
| Panel Brand : | AUO |
| Panel Model : | G104SN03 V5 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 10.4 inch |
| Resolution : | 800(RGB)×600 , SVGA |
| Display Mode : | TN, Normally White, Transmissive |
| Active Area : | 211.2×158.4 mm |
| Outline : | 236×176.9×6 mm |
| Surface : | Antiglare, Hard coating (3H) |
| Brightness : | 230 cd/m² (Typ.) |
| Contrast Ratio : | 500:1 (Typ.) |
| Display Colors : | 262K/16.2M (6-bit / 6-bit + FRC) , CIE1931 50% |
| Response Time : | 10/5 (Typ.)(Tr/Td) |
| Viewing Angle : | 80/80/60/70 (Typ.)(CR=10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 3 strings WLED Embedded (LED Driver) |
| Signal Interface : | LVDS (1 ch, 6/8-bit) , 20 pins |
| Input Voltage : | 3.3V (Typ.) |
