Product Details:
|
| Panel Type: | A-Si TFT-LCD , Panel | Resolution: | 1920(RGB)×1080 , FHD |
|---|---|---|---|
| Display Mode: | S-PVA, Normally Black, Transmissive | Active Area: | 1018.08×572.67 Mm |
| Contrast Ratio: | 3500:1 (Typ.) | Panel Size: | 46 Inch |
| Brightness: | 700 Cd/m² (Typ.) | Surface: | Antiglare (Haze 44%), Hard Coating (3H) |
| High Light: | industrial touch screen display,industrial lcd screen |
||
46 Inch LTI460HA03 FHD Industrial LCD Displays 1920*1080 Resolution
Our advantages
1. Your reply will be replied within 24 hours.
2. Good service whenever.
3. OEM service
4. No MOQ request.
5. Quick delivery: 1-3 working days
6. Each LCD panel will be tested pcs by pcs by our professional testing team.
7. One Year warranty for our LCD Screen Displays.
SAMSUNG LTI460HA03 General Features
Panel Brand : SAMSUNG
Panel Model : LTI460HA03
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 46 inch
Resolution : 1920(RGB)×1080 , FHD
Display Mode : S-PVA, Normally Black, Transmissive
Active Area : 1018.08×572.67 mm
Outline : 1047.4×600.6×66 mm , Videowall Seam 29.3 mm
Surface : Antiglare (Haze 44%), Hard coating (3H)
Brightness : 700 cd/m² (Typ.)
Contrast Ratio : 3500:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 72%
Response Time : 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
Viewing Angle : 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 16 pcs CCFL Embedded (Inverter)
Signal Interface : LVDS (2 ch, 8-bit) , 51 pins
Input Voltage : 12.0V (Typ.)
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| P101LCA-3P1 | Innolux | 10.1" | 1920×1200 |
| V650HP2-PS5 | Innolux | 65" | 1920×1080 |
| N156HGE-DB1 | Innolux | 15.6" | 1920×1080 |
| V500DJ4-QS1 | Innolux | 50" | 3840×2160 |
| V500DJ2-QS5 | Innolux | 50" | 3840×2160 |
| V400DJ1-QS5 | Innolux | 40" | 3840×2160 |
| P089DCZ-3A1 | Innolux | 8.9" | 800×1280 |
We also have other industrial LCD panels, pls contact to us for the further information: salespm@nselectronic.com.hk
Basic Information
Panel Model : LTI460HA03
Panel Type : a-Si TFT-LCD , Panel
Operating Temperature : 0 ~ 50 °C
Storage Temperature : -20 ~ 60 °C
| Panel Size : | 46 inch |
| Dot Resolution : | 1920(RGB)×1080 (FHD) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 47 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.17675×0.53025 mm (H×V) |
| Pixel Pitch : | 0.53025×0.53025 mm (H×V) |
| Weight : | 16.0Kgs (Max.) |
| Surface : | Antiglare (Haze 44%), Hard coating (3H) |
| Active Area : | 1018.08×572.67 mm (H×V) |
| Bezel Area : | 1024.4×578.6 mm (H×V) |
| Outline Dimension : | 1047.4×600.6 mm (H×V) |
| Outline Depth : | 41.8/66.0 (Typ./Max.) mm |
| Videowall Seam : | 29.3 mm (Active to Active) |
| Landscape or Portrait : | Landscape / Portrait |
| Touch Panel : | Without |
SAMSUNG LTI460HA03 Optical Features
Display Mode : S-PVA, Normally Black, Transmissive
Brightness : 700 cd/m² (Typ.)
Contrast Ratio : 3500 : 1 (Typ.) (Transmissive)
Display Color : 16.7M (8-bit)
Color Gamut : 72% NTSC (CIE1931)
Response Time : 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
Viewing Angle : 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction : Symmetry
White color Chromaticity : Wx:0.280; Wy:0.290
White Variation : 1.33 (Max.)(9 points)
SAMSUNG LTI460HA03 Backlight System
| Lamp Position : | Direct light type |
| Lamp Type : | CCFL |
| Lamp Amount : | 16 pcs |
| Lamp Shape : | Straight |
| Lamp Life Time : | 50K(Min.) (Hours) |
| Lamp Voltage : | 1070/1120/1260V (Min./Typ./Max.) |
| Lamp Current : | 5.0/10.0/12.0mA (Min./Typ./Max.) |
| Interface Type : | Connector |
