Product Details:
|
| Size: | 15.0" | Resolution: | 1024×768 |
|---|---|---|---|
| Display Scale: | 4:3 | Luminance: | 300 Nits |
| Active Area: | 304.128×228.096 Mm | Outline: | 327.00× 254.00×10.00 M |
| High Light: | auo display panel,auo lcd display |
||
15 Inch G150XVN01 V0 Original AUO lcd panel replacement Full Viewing Angle
Products Basic Information
| Model | G150XVN01-V0 |
| Size | 15 inch |
| Productor | AUO |
| Resolution | 1024×768 |
| Display scale | 4:3 |
| Luminance | 300 nits |
| Contrast Ratio | 1500:1 |
| Color | 262K/16.2M |
| Technology | a-Si TFT-LCD |
| Interface | LVDS |
| Backlight | LED |
| Active Area | 304.128×228.096 mm |
| Outline | 327.00× 254.00×10.00 mm |
| Viewing Angle | 89/89/89/89(U/D/L/R) |
Warranty:
(1) All panels’ grade is promised strictly same as original factory’s standard.
(2) All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.
(3) We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.
(4) ISO 9001 guarantee.
Return and Refund:
(1) Please notify us ASAP if the LCD Displays you received is defective. Please do not raise any dispute without communication.
(2) All LCD panels must be informed before returning. Defective item must be reported and returned within our warranty period.
(3) Returned item must have original package and be in good condition if possible, pls provide us the tracking number and returning reason.
Product Features
Resolution: 1024×768
Resolution Name: XGA
Display scale: 4:3
Pixel Pitch: 0.099×0.297 mm
Panel Composition: LCD Screen
Technology: a-Si TFT-LCD
Luminance: 300 nits
Contrast Ratio: 1500:1
Color: 262K/16.2M
Viewing Angle: 89/89/89/89(L/R/U/D)
Interface: LVDS
Operation Temperature: -10 °C ~ 70 °C
Active Area: 304.128×228.096 mm
Outline: 327.00× 254.00×10.00 mm
Backlight: LED
