Product Details:
|
| Productor: | AUO | Luminance: | 350 Nits |
|---|---|---|---|
| Color: | 16.2M | Interface: | LVDS |
| Display Mode: | TN, Normally White, Transmissive | Active Area: | 304.128×228.096 Mm |
| Operation Temperature: | -20 °C ~ 70 °C | Life Time Of Lamp: | 50K Hours |
| High Light: | auo display panel,auo lcd display |
||
WLED Backlight 15'' 1024*768 AUO LCD Screen G150XTN01.1 for industry
AUO G150XTN01.1 General Features
Panel Brand : AUO
Panel Model : G150XTN01.1
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 15.0 inch
Resolution : 1024(2)×768(2) , XGA
Display Mode : TN, Normally White, Transmissive
Active Area : 304.128×228.096 mm
Outline : 326.5×253.5 mm
Surface : Antiglare, Hard coating (3H)
Brightness : 350 cd/m² (Typ.)
Contrast Ratio : 700:1 (Typ.)
Display Colors : 16.2M (6-bit + FRC) , CIE1931 60%
Response Time : 5.7/2.3 (Typ.)(Tr/Td)
Viewing Angle : 80/80/60/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : WLED
Signal Interface : LVDS (1 ch, 8-bit) , 20 pins
Input Voltage : 3.3V (Typ.)
Technical Specifications
| active Area (mm) | 304.128×228.096 mm |
| Number of Pixels | 1024(2) × 768(2),XGA |
| Pixel Pitch (mm) | 0.297×0.297 mm (H×V) |
| Color Pixel Arrangement | RGBW Rectangle |
| Number of Colors | 16.2M |
| Brightness (cd/m^2) | 350nit |
| Response Time (ms) | 5.7/2.3 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) (L/R/U/D) |
| Module Size (mm) | 326.5×253.5 mm (H×V) |
| backlight | WLED |
Competitive Advantage:
1. We are a leading vendor & distributor for the LCD panels for more than 6 years.
2. We got the ISO9001 quality management system certification.
3. We have our own sourcing line & agency for the hard-to-find & shortage LCD panel models.
4. We are the professional team for the LCD screen sourcing & international trade with 6-year experience.
5. Prompt delivery, we always have the LCD panels in stock. Delivery can be made in 1-3 working days.
6. 1-year warranty is offered.
7. All LCD Panel will be tested before shipment.
8. We are the vendor & distributor in LCD panel area already for 6 years. We own our professional & competitive LCD screen sourcing line.
Packaging & Delivery
| Delivery Lead Time : | 2~3 weeks |
| Minimum Order : | 1 pcs LCD Panel |
| Supply Ability : | 100 PCS / Per Day |
Quality Control:
| Visual Inspection | Make sure No damage, No Scratches, No dusty, No light leakage. |
| Function Inspection | Make sure all functions are 100% tested ok. |
Product Details for AUO G150XTN01.1
