EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel

EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel

    • EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel
    • EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel
  • EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel

    Product Details:

    Place of Origin: Japan,Korea
    Brand Name: Chimei LCD Panel
    Certification: ISO9001
    Model Number: EE070NA-01D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Packaging Details: Antistatic bag, Bubble Bag, Foam Box and Carton Box.
    Delivery Time: 1-3 Working Days
    Payment Terms: T/T, Western Union, MoneyGram, Paypal
    Supply Ability: 100 PCS PER DAY
    Contact Now
    Detailed Product Description
    Panel Brand: CHIMEI INNOLUX Panel Model: EE070NA-01D
    Panel Type: A-Si TFT-LCD , CELL Panel Size: 7.0 Inch
    Active Area: 153.6×90 Mm Outline: 160×101.1×1.43 Mm
    Surface: Glare (Haze 0%), Hard Coating Glass Depth: 0.50+0.50 Mm



    EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel



    Company Strength



    1. ISO9001 certificated, Factory Direct Supplied

    2. RoHS Compliant, Lead Free, Reach Compliant

    3. Competitive Price and Short Lead-time

    4. Professional Team with Rich Experiences in Design/Mfg/Quality Control

    5. Small MOQ Support & Fast Response to Customers

    6. Long Product Life Time



    Our Service

    • Long lasting product cycle for continuity thru all phases of project rollouts and servicing

    • Easy-to-install console, Open Frame chassis-mount display

    • Slim dimensions enable better enclosure designs

    • Multiple mounting options (100mm VESA mount and side brackets)

    • All steel construction provides rugged frame for public use environments

    • Two independent touch points (with Windows 7 OS)

    • Improved power efficiency and reduced consumption

    • TUV, CE, UL, CUL, FCC-B, RoHS, and IPX1 approvals



    CHIMEI INNOLUX EE070NA-01D General Features

    Panel Brand : CHIMEI INNOLUX
    Panel Model : EE070NA-01D
    Panel Type : a-Si TFT-LCD , CELL
    Panel Size : 7.0 inch
    Resolution : 1024(RGB)×600 , WSVGA
    Display Mode : TN, Normally White, Transmissive
    Active Area : 153.6×90 mm
    Outline : 160×101.1×1.43 mm
    Surface : Glare (Haze 0%), Hard coating
    Glass Depth : 0.50+0.50 mm
    Transmissivity : 3.5% (Typ.)(with Polarizer)
    Contrast Ratio : 700:1 (Typ.)
    Display Colors : 262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Response Time : 10/15 (Typ.)(Tr/Td)
    Viewing Angle : 75/75/70/75 (Typ.)(CR≥10) (L/R/U/D)
    Frequency : 60Hz
    Signal Interface : LVDS (1 ch, 6/8-bit) , 40 pins
    Input Voltage : 3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL)



    CHIMEI INNOLUX EE070NA-01D Optical Features

    Display Mode : TN, Normally White, Transmissive
    Brightness : 0 cd/m²
    Contrast Ratio : 700 : 1 (Typ.) (Transmissive)
    Display Color : 262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Response Time : 10/15 (Typ.)(Tr/Td)
    Viewing Angle : 75/75/70/75 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction : 6 o'clock
    White color Chromaticity : Wx:0.299; Wy:0.323
    Transmissivity : 3.5% (Typ.)(with Polarizer)



    Details Pictures for Chimei LCD Panel EE070NA - 01D Chimei LCD Panel , Hard coating lcd flat panel
