Product Details:
|
| Operating Temp.: | 0 ~ 50 °C | Storage Temp.: | -20 ~ 60 °C |
|---|---|---|---|
| Contrast Ratio: | 1000 : 1 (Typ.) (TM) | Work Mode: | AHVA, Normally Black, |
| Viewing Angle: | 89 (Typ.)(CR≥10) | Luminance: | 800 Cd/m² (Typ.) |
| High Light: | 8" AUO LCD Panel,G080UAN01.1 LCD Panel,8bit AUO LCD Panel |
||
8bit G080UAN01.1 8" 0.0897mm Pixel AUO LCD Panel Military Display
Description Of AUO LCD Panel
G080UAN01.1 supports display 1200(RGB)×1920 (WUXGA) with aspect ratio of 10:16 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 107.64(W)×172.224(H) mm. As a AHVA, Normally Black, Transmissive LCM product, G080UAN01.1 can provides 800 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 27 (Typ.)(Tr+Tf) ms.
Below are our other LCD panels stock for your easy reference:
| M238HVN01.2 CELL | AUO | 23.8" |
| T320XVN02.F CELL | AUO | 31.5" |
| T430HVN01.6 CELL | AUO | 43" |
| B101EAN01.2 CELL | AUO | 10.1" |
| H497EAN01.0 | AUO | 5.0" |
| T320XVN02.C CELL | AUO | 31.5" |
| T320HVN05.8 CELL | AUO | 31.5" |
| T500HVN07.5 CELL | AUO | 50" |
| B070EAN02.0 CELL | AUO | 7.0" |
| M320QAN01.0 CELL | AUO | 32.0" |
| H546TAN02.0 | AUO | 5.5" |
| H598TAN01.0 | AUO | 6.0" |
| H546DAN03.3 | AUO | 5.5" |
| H497DAN02.0 | AUO | 5.0" |
| H495TAN01.1 | AUO | 5.0" |
| H496TAN01.0 | AUO | 5.0" |
| H496TAN01.0 | AUO |
5.5" |
Application Of AUO LCD Panel G080UAN01.1
1. Military Display
2. Industrial Display
3. Self-service Display
4. Tablet PC
