High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen

High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen
High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen

Large Image :  High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen

Product Details:
Place of Origin: TaiWan
Brand Name: AUO
Model Number: G101UAN02.0
Payment & Shipping Terms:
Minimum Order Quantity: 500
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: Western Union,PAPLY,BANK TRANSFER
Supply Ability: 500

High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen

Description
Manufacturer: AUO Model Name: G101UAN02.0
Screen Size: 10.1 Inch Screen Type: LCM, A-Si TFT-LCD
Pixel Number: 1920(RGB)×1200 (WUXGA) 224PPI Touchscreen: Without
High Light:

High Brightness AUO LCD Panel

,

1920×1200 AUO LCD Panel

,

G101UAN02.0

High Brightness AUO LCD Panel G101UAN02.0 Without Touchscreen



G101UAN02.0 AUO 10.1" LCM 1920×1200 Without Touchscreen And Industrial,Outdoor High Brightness



AUO G101UAN02.0 Mechanical Details

Pixel Features :
Pixel Format
1920(RGB)×1200, WUXGA
Dot Pitch
0.038×0.113 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.113×0.113 mm (H×V) [224PPI]
Mechanical Size :
Display Area
216.81×135.5 mm (H×V)
Outline Dim.
-
Outline Dim.
229.4×150.5 mm (H×V)
Outline Depth
2.7/5.05 (Typ./Max.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:10 (H:V)
Shape Style

Holes & Brackets :
Without
Other Features :
Weight
170g (Max.)
Surface
Hard coating, Antireflection
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.



AUO G101UAN02.0 Optical Details

Basic Information :
Brightness
800 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
AHVA, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
25 (Typ.)(Tr+Td) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
16.7M (6-bit + Hi-FRC)
Color Temperature
6485K
Uniformity
1.43 (Max.)(5 points)
1931 Color Gamlt :
NTSC Ratio
53%
sRGB
74% coverage
Adobe RGB
55% coverage
DCI-P3
55% coverage
Rec.2020
40% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :
Outdoor Visibility
Sunlight Readable
Transmittance
-
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.



Here comes our other LCD panels stock for your easy reference:

Pls contact to us for more stock information





Panel Model Brand Size
X139BLB01.0 AUO 1.39"
H381DLN01.0 AUO 3.8"
H497TLB01.4 AUO 5.0"
H163QLN01.0 AUO 1.63"
H139BLN01.2 AUO 1.39"
H500TLB01.0 AUO 5.0"
X546DLB01.0 AUO 5.5"
H546DLB01.1 AUO 5.5"
H429ALN01 V0 AUO 4.3"
H139BLN01.1 AUO 1.39"
H163QLN01.1 AUO 1.63"
H497TLB01 AUO 5.0"
H497TLB01.0 AUO 5.0"







Q1: Can I place sample order first?

A1: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.

Q2: How could I pay them?

A2: We accept T/T, Western Union, MoneyGram, Paypal.

Q3: How to place the order?

A3: Please send us your purchase order by e-mail, whatsapp or Skype or you can ask us to send you a Proforma Invoice for your order.

Q4: How long can I get my order?

A4: For samples, we will finish production and ship within 1-3 working days. For bulk orders, that will base on the order quantity.

Q5: How to send us the products?

A5: We usually use DHL, UPS, FedEx to ship our LCD screen replacements to our clients.



The reasons you choose us

1).More competitive price! As a professional LCD Distributor, we have our own souring lines &solutions to support us for the more competitive service, not only the price, but also the stock for the hard-to-find LCD panels.

2).Great quality! All LCD Screen we sent are with good quality guarantee, 100% quality check and full one year warranty!
3).Fast delievery! Delivery time will be faster than others.
4).Great shipping service! We have cooperated with DHL,UPS and EMS for long time, so we could promise save much more money on the shipping cost and better service is offered!
5).Best sale-service! Professional team to service with you before sale, on sale & after service.
