10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial

10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial
10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial 10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial

Large Image :  10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial

Product Details:
Place of Origin: Taiwan
Brand Name: AUO
Model Number: G101EVT03.2
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: pls contact us
Packaging Details: standard Packaging
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union,PAPLY,BANK TRANSFER
Supply Ability: 1000

10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial

Description
Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) Color Depth: 262K 45% NTSC
Refresh Rate: 60Hz Contrast Ratio: 1300 : 1 (Typ.) (TM)
Work Mode: MVA, Normally Black, Transmissive Response: 25 (Typ.)(Tr+Td) Ms
High Light:

Symmetry Tft Display Panel

,

AUO Tft Display Panel

,

G101EVT03.2 AUO Panel

10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial



AU Optronics Corp. (hereafter called AUO) G101EVT03.2 is a 10.1 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system. G101EVT03.2 supports display 1280(RGB)×800 (WXGA) with aspect ratio of 16:10 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 216.96(W)×135.6(H) mm.



AUO G101EVT03.2 Mechanical Details

Pixel Features :
Pixel Format
1280(RGB)×800, WXGA
Dot Pitch
0.0565×0.1695 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.1695×0.1695 mm (H×V) [149PPI]
Mechanical Size :
Display Area
216.96×135.6 mm (H×V)
Outline Dim.
-
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:10 (H:V)
Shape Style


AUO G101EVT03.2 Optical Details

Basic Information :
Brightness
-
Contrast Ratio
1300:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Optical Mode
MVA, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
25 (Typ.)(Tr+Td) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
262K (6-bit)
Color Temperature
6485K
Uniformity
1.25/1.50 (Max.)(5/13 points) 10.1" G101EVT03.2 1280×800 AUO Symmetry Tft Display Panel For Industrial 0
1931 Color Gamlt :
NTSC Ratio
47%
sRGB
66% coverage
Adobe RGB
49% coverage
DCI-P3
49% coverage
Rec.2020
35% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



We also have other industrial LCD panels, pls contact to us for the further information



H496TAN01.0 AUO 5.2"
H496TAN01.0 AUO 1.6"
H496TAN01.0 AUO 4.6"
H496TAN01.0 AUO 5.2"
H496TAN01.0 AUO 4.5"
H496TAN01.0 AUO 4.7"
H496TAN01.0 AUO 5.0"
H496TAN01.0 AUO 4.3"
H496TAN01.0 AUO 43"
H496TAN01.0 AUO 31.5"
H496TAN01.0 AUO 31.5"



Application Of AUO LCD Panel G101EVT03.2

1. Tablet PC

2. Medical Display

3. Industrial Display

4. Commercial Display
