Product Details:
|
| Size: | 15 Inch | Resolution: | 1024×768 |
|---|---|---|---|
| Luminance: | 500 (Typ.)(cd/m²) | Pixel Number: | 1024(RGB)×768 (XGA) |
| Arrangement: | RGB Vertical Stripe | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Response: | 25 (Typ.)(Tr+Td) Ms | Color Depth: | 16.2M 60% NTSC |
| Backlight: | WLED , 50K Hours , With LED Driver | Touchscreen: | Without |
| High Light: | auo lcd screen,auo lcd display |
||
| Pixel Features : | Pixel Format | 1024(RGB)×768 [XGA] | Dot Pitch | 0.099×0.297 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.297×0.297 mm (H×V) | |
| Mechanical Size : | Display Area | 304.128×228.096 mm (H×V) | Bezel Area | 309.9×236.3 mm (H×V) |
| Outline Dim. | 326.5×2535 mm (H×V) | Outline Depth | 6.8 (Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | - | |
| Holes & Brackets : | Side mounting holes (4-M2) on left, right bezel | |||
| Other Features : | Weight | 660g (Max.) | Surface | Antiglare, Hard coating (3H) |
2.AUO G150XAN01.2 Optical Details
| Basic Information : | Brightness | 500 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Optical Mode | AHVA, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 25 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 16.2M (6-bit + FRC) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 60% | sRGB | 78% coverage |
| Adobe RGB | 62% coverage | DCI-P3 | 62% coverage | |
| Rec.2020 | 44% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
