Product Details:
|
| Size: | 15 Inch | Screen Type: | LCM , A-Si TFT-LCD |
|---|---|---|---|
| Resolution: | 1024(RGB)×768 , XGA | Pixel Format: | RGB Vertical Stripe |
| Display Area: | 304.128(W)×228.096(H) Mm | Bezel Opening: | 311.9(W)×236.85(H) Mm |
| Outline Size: | 326.5(W)×253.5(H) ×10(D) Mm | Surface: | Antiglare |
| Brightness: | 1800 Cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) (TM) |
| Viewing Angle: | 80/80/70/80 (Typ.)(CR≥10) | Application: | Industrial |
| High Light: | auo lcd screen,auo lcd display |
||
| Basic Information : | Luminance | 1800 cd/m² (Typ.) | Contrast Ratio | 800 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | - | Response Speed | 5.7/2.3 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 262K/16.2M (6-bit / 6-bit + FRC) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 60% | sRGB | 84% coverage |
| Adobe RGB | 63% coverage | DCI-P3 | 63% coverage | |
| Rec.2020 | 45% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
2.AUO G150XTN06.A Mechanical Details
| Pixel Features : | Number of Pixel | 1024(RGB)×768 [XGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.099×0.297 mm | Pixel Pitch(W×H) | 0.297×0.297 mm | |
| Physical Size : | Active Viewing | 304.128(W)×228.096(H) mm | Overall Dim. | 326.5(W)×253.5(H) mm |
| Bezel Opening | 311.9(W)×236.85(H) mm | Overall Depth | 10 (Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style | - | |
| Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Detail : | Mass | 1.00Kgs (Max.) | Surface |
Antiglare |
